Buffalo TeraStation 6200DN NAS Desktop Intel Atom® C3338
Buffalo

TeraStation 6200DN NAS Desktop Intel Atom® C3338

8 GB DDR4 8 TB HDD Linux Black

Model 6200DNPart no. TS6200DN0802-EUEAN 4981254052051

89 specifications
  • ProcessorIntel Atom®
  • Memory8 GB
  • TypeNAS
  • OSLinux
  • Weight5 kg
  • ColourBlack
See all specifications

Overview

Processor
Intel Atom®
Memory
8 GB
Type
NAS
OS
Linux
Weight
5 kg
Colour
Black
Brand
Buffalo
Model
6200DN
Part numbers
TS6200DN0802-EU, TS6200DN0402-EU
EAN / UPC
4981254052051, 4981254052044
Also known as
Buffalo TeraStation 6200DN NAS Desktop Intel Atom® C3338 8 GB DDR4 8 TB HDD Linux Black

Specifications

89 specifications in 14 groups

Storage

Storage drives installedYes
Total installed storage capacity8 TB
Number of storage drives installed2
Number of storage drives supported2
Installed storage drive typeHDD
Supported storage drive typesHDD
Storage drive capacity4 TB
Storage drive interfaceSerial ATA III
Supported storage drive interfacesSerial ATA III
RAID supportYes
RAID levels0, 1, JBOD
Hot-swap drive baysYes

Processor

Processor manufacturerIntel
Processor familyIntel Atom®
Processor modelC3338
Processor frequency1.5 GHz
Processor boost frequency2.2 GHz
Processor cores2
Processor threads2
Processor cache4 MB
CPU configuration (max)1
PCI Express configurations1x2, 1x4, 1x8
PCI Express slots version3.0
Processor codeSR36E
Processor codenameDenverton
Processor lithography14 nm
Processor operating modes64-bit
Processor package size34 x 28 mm
Processor socketBGA 1310
SteppingB0
Tcase89 °C
Thermal Design Power (TDP)9 W
Tjunction100 °C
Maximum internal memory supported by processor64 GB
Conflict-Free processorYes

Memory

Internal memory8 GB
Internal memory typeDDR4

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000,2500,5000,10000 Mbit/s
Ethernet LAN data rate supported (max)10000 Mbit/s
Wi-FiNo
iSCSI supportYes
Supported network protocolsTCP/IP, UDP

Ports & interfaces

Ethernet LAN (RJ-45) ports3
USB portYes
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Fiber ports quantity0

Design

Chassis typeDesktop
Product colourBlack

Performance

TypeNAS
Device classHome & Home Office
Backup functionYes
Backup featuresCloud, iSCSI LUN
Web-based managementYes

Software

Operating system installedLinux
Windows operating systems supportedWindows 10, Windows 7, Windows 8.1
Mac operating systems supportedMac OS X 10.11 El Capitan
Server operating systems supportedWindows Server 2008, Windows Server 2012, Windows Server 2016

Power

Power consumption (max)85 W
Power consumption (typical)31 W
Power consumption (HDD standby)6 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Weight & dimensions

Width170 mm
Depth230 mm
Height170 mm
Weight5 kg

Packaging content

Cables includedAC
Quick start guideYes

Processor special features

Embedded options availableYes
Execute Disable BitYes
Intel QuickAssist TechnologyNo
Intel Secure BootYes
Intel Secure Boot Technology version1.00
Intel Secure Key Technology version1.00
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® OS GuardYes
Intel® Secure KeyYes
Intel® Turbo Boost Technology2.0
Maximum number of PCI Express lanes10
Memory types supported by processorDDR3L, DDR4-SDRAM

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 85%

Other features

Processor ARK ID97928
