Buffalo 5400DN WSS

Model 5400DN WSSPart no. WS5400DN0404W2EAN 747464130972

100 specifications

Overview

Brand: Buffalo
Category: NAS & Storage Servers
Model: 5400DN WSS
Part numbers: WS5400DN0404W2, WS5400DN0804W2, WS5400DN1204W2
EAN / UPC: 747464130972, 747464130958, 747464130965
Also known as: Buffalo TeraStation 5400DN WSS NAS Compact Intel Atom® D2550 4 GB DDR3 4 TB HDD Windows Storage Server 2016 Black

100 specifications in 15 groups

Specification	Value
Storage drives installed	Yes
Total installed storage capacity	4 TB
Number of storage drives installed	4
Number of storage drives supported	4
Installed storage drive type	HDD
Supported storage drive types	HDD
Storage drive capacity	1 TB
Storage drive interface	Serial ATA II
Supported storage drive interfaces	Serial ATA, Serial ATA II
Storage drive size	3.5"
Storage drive sizes supported	3.5"
Maximum supported storage capacity	24 TB
RAID support	Yes
RAID levels	0, 1, 5, JBOD
Hot-swap drive bays	Yes

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D2550
Processor frequency	1.86 GHz
Processor cores	2
Processor threads	4
Processor cache	1 MB
L2 cache	1 MB
Bus type	DMI
ECC supported by processor	No
Physical Address Extension (PAE)	36 bit
Processor cache type	L2
Processor code	SR0VY
Processor codename	Cedarview
Processor lithography	32 nm
Processor operating modes	64-bit
Processor package size	22 X 22 mm
Processor socket	BGA 559
Stepping	B3
Thermal Design Power (TDP)	10 W
Tjunction	100 C
On-board graphics card model	Intel® GMA 3650
Maximum internal memory supported by processor	4 GB
Memory bandwidth supported by processor (max)	6.4 GB/s
Conflict-Free processor	No

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
iSCSI support	Yes
Supported network protocols	TCP, IP, UDP

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	Yes
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Fiber ports quantity	0
VGA (D-Sub) ports quantity	1

Specification	Value
On-board graphics card base frequency	640 MHz
Number of displays supported (on-board graphics)	2

Specification	Value
Operating system installed	Windows Storage Server 2016
Operating system version	Workgroup Edition
Windows operating systems supported	Yes
Mac compatibility	Yes
Mac operating systems supported	Yes

Specification	Value
Cables included	AC, LAN (RJ-45)
Quick start guide	Yes

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Intel 64	Yes
Intel Dual Display Capable Technology	Yes
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	No
Maximum number of PCI Express lanes	4
Physical Address Extension (PAE)	Yes
Memory channels supported by processor	Single
Memory types supported by processor	DDR3-SDRAM

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Specification	Value
Compliance certificates	RoHS
Processor ARK ID	65470
