TeraStation 3220DN NAS Desktop Alpine AL214
1 GB DDR3 2 TB HDD Linux Black
Model 3220DNPart no. TS3220DN0402EAN 747464134215
50 specifications
- ProcessorAlpine
- Memory1 GB
- TypeNAS
- OSLinux
- Weight4.4 kg
- ColourBlack
Overview
- Processor
- Alpine
- Memory
- 1 GB
- Type
- NAS
- OS
- Linux
- Weight
- 4.4 kg
- Colour
- Black
- Brand
- Buffalo
- Category
- NAS & Storage Servers
- Model
- 3220DN
- Part numbers
- TS3220DN0402, TS3220DN0202-EU, TS3220DN0802-EU, TS3220DN0402-EU, TS3220DN0802
- EAN / UPC
- 747464134215, 4981254052969, 4981254052945, 4981254052952 +1 more
- Also known as
- Buffalo TeraStation 3220DN NAS Desktop Alpine AL214 1 GB DDR3 2 TB HDD Linux Black
Specifications
50 specifications in 11 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Total installed storage capacity | 2 TB |
| Number of storage drives installed | 2 |
| Number of storage drives supported | 2 |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 1 TB |
| Storage drive interface | Serial ATA III |
| Supported storage drive interfaces | Serial ATA III |
| RAID support | Yes |
| RAID levels | 0, 1, JBOD |
| Hot-swap drive bays | Yes |
Processor
| Specification | Value |
|---|---|
| Processor family | Alpine |
| Processor model | AL214 |
| Processor frequency | 1.4 GHz |
| Processor cores | 4 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 1 GB |
| Internal memory type | DDR3 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Wi-Fi | No |
| iSCSI support | Yes |
| Supported network protocols | TCP/IP |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | Yes |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Fiber ports quantity | 0 |
Design
| Specification | Value |
|---|---|
| Chassis type | Desktop |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Backup features | Cloud |
| Web-based management | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | Linux |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.11 El Capitan |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 85 W |
| Power consumption (typical) | 33 W |
| Power consumption (HDD standby) | 0.93 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 170 mm |
| Depth | 230 mm |
| Height | 170 mm |
| Weight | 4.4 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 85% |
