ASUS AS3204T v2

ASUS AS3204T v2

Model AS3204T v2Part no. 90IX00W1-BW3S20EAN 887372001114

66 specifications
  • ProcessorIntel® Celeron®
  • Memory2 GB
  • Noise19.7 dB
  • TypeNAS
  • OSADM
  • Weight1.6 kg
See all specifications

Overview

Processor
Intel® Celeron®
Memory
2 GB
Noise
19.7 dB
Type
NAS
OS
ADM
Weight
1.6 kg
Brand
ASUS
Model
AS3204T v2
Part number
90IX00W1-BW3S20
EAN / UPC
887372001114, 4710474831098
Also known as
ASUS AS3204T v2 NAS Intel® Celeron® 2 GB DDR3L 0 TB ADM Black

Specifications

66 specifications in 13 groups

Storage

Storage drives installedNo
Total installed storage capacity0 TB
Number of storage drives installed0
Number of storage drives supported4
Installed storage drive typeNo
Supported storage drive typesHDD
Storage drive interfaceSerial ATA II, Serial ATA III
Storage drive size3.5"
Maximum supported storage capacity48 TB
RAID supportYes
RAID levels0, 1, 5, 6, 10
Supported file systemsFAT32, HFS+, NTFS, ext3, ext4

Processor

Processor familyIntel® Celeron®
Processor frequency1.6 GHz
Processor cores4

Memory

Internal memory2 GB
Internal memory typeDDR3L
Maximum RAM supported2 GB

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Jumbo frames supportYes
iSCSI supportYes
Wake-on-LAN readyYes
Supported network protocolsCIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI, HTTP, HTTPS, Proxy, SNMP, Syslog

Ports & interfaces

Ethernet LAN (RJ-45) ports2
USB portYes
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
HDMI ports quantity1

Design

Cooling typeActive
Product colourBlack
Number of fans1 fan(s)
Fan diameter12 cm

Performance

TypeNAS
Device classHome & Home Office
Backup functionYes
Backup featuresCloud
Number of users4096 user(s)
Noise level19.7 dB
Share folder access right managementYes
Web-based managementYes
Access Control List (ACL)Yes
Browser supportedWindows Edge / Chrome / Firefox, Mac Safari
Built-in FTP serverYes
Built-in UPnP AV media serverYes
Built-in iTunes serverYes
Security algorithms256-bit AES
System logYes

Software

Operating system installedADM
Operating system version3.1
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows
Linux operating systems supportedYes
Mac operating systems supportedMac OS X 10.6 Snow Leopard
Server operating systems supportedWindows Server 2003, Windows Server 2008, Windows Server 2012

Power

Power supply locationBuilt-in
Power consumption (typical)26.3 W
Power consumption (sleep)0.97 W
AC input voltage100-240 V

Weight & dimensions

Width164 mm
Depth218 mm
Height165 mm
Weight1.6 kg

Operational conditions

Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)5 - 95%

Logistics data

Harmonized System (HS) code84714100

Other features

CertificationFCC, CE, VCCI, BSMI, C-TICK
