ASUS AS-204TE NAS Intel Atom® Z2520

1 GB DDR3 ADM Black

Model AS-204TEPart no. 90IX0011-BW3S10EAN 4053162921665

78 specifications

Overview

78 specifications in 14 groups

Specification	Value
Storage drives installed	No
Number of storage drives supported	4
Supported storage drive types	HDD & SSD
Storage drive interface	Serial ATA III
Storage drive size	2.5/3.5"
RAID support	Yes
RAID levels	1, 5, 6, 10
Hot-swap drive bays	Yes

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	Z2520
Processor frequency	1.2 GHz
Processor cores	2
Processor threads	4
Processor cache	1 MB
CPU configuration (max)	1
Number of processors installed	1
Physical Address Extension (PAE)	32 bit
Processor cache type	Smart Cache
Processor code	SR161
Processor lithography	32 nm
Processor operating modes	32-bit
Processor package size	14 x 14 mm
Processor socket	FC-MB4760
Stepping	B1
Tjunction	90 °C
Maximum internal memory supported by processor	2 GB
Memory bandwidth supported by processor (max)	8.5 GB/s
Conflict-Free processor	Yes

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
VGA (D-Sub) ports quantity	0
Serial ports quantity	0

Specification	Value
On-board graphics card base frequency	300 MHz
Number of displays supported (on-board graphics)	2

Specification	Value
Cooling type	Active
Product colour	Black

Specification	Value
Operating system installed	ADM
Operating system version	2.6

Specification	Value
Power consumption (typical)	36 W

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Graphics & IMC lithography	32 nm
Idle States	Yes
Intel Enhanced Halt State	Yes
Intel Smart Idle Technology	Yes
Intel Smart Idle Technology version	1.00
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	No
Thermal Monitoring Technologies	Yes
UART	Yes
Memory channels supported by processor	Dual
Memory types supported by processor	LPDDR2-SDRAM

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 95%

Specification	Value
Compatible operating systems	Windows XP, Vista, 7, 8, 10, Server 2003, Server 2008, Server 2012 Mac OS X 10.6 Onwards UNIX, Linux, and BSD
Security features	AES 256-Bit, Alert Notifications: E-mail, SMS,
Supported protocols	CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI, HTTP, HTTPS, Proxy, SNMP, Syslog
Certification	FCC, CE, VCCI, BSMI, C-TICK
Processor ARK ID	75203
