4-Port Multi-Device USB-C Charger
240W Total, Single Port 140W EPR, PD 3.1, Screw Locking Ports, Surface Mounting, Ideal for Boardrooms, 2x 10ft U
Model 424D3N-USB-C-CHARGEREAN 065030915205
48 specifications
- Power260 W
- Weight563 g
- ColourSilver
- Charger typeIndoor
- Input voltage100 - 240 V
- Width88 mm
Overview
- Power
- 260 W
- Weight
- 563 g
- Colour
- Silver
- Charger type
- Indoor
- Input voltage
- 100 - 240 V
- Width
- 88 mm
- Brand
- StarTech.com
- Category
- Mobile Device Charger
- Model
- 424D3N-USB-C-CHARGER
- Part number
- 424D3N-USB-C-CHARGER
- EAN / UPC
- 065030915205
- Also known as
- StarTech.com 4-Port Multi-Device USB-C Charger, 240W Total, Single Port 140W EPR, PD 3.1, Screw Locking Ports, Surface Mounting, Ideal for Boardrooms, 2x 10ft U
Specifications
48 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Universal |
| Power source type | AC |
| USB Type-C ports quantity | 4 |
| Fast charging | Yes |
| Fast charging technology | Power Delivery 3.1 |
| Number of simultaneously connected devices (max) | 4 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.1 |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
| Cable length | 1.16 m |
| Housing material | Plastic |
| Gallium nitride (GaN) transistors | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Input current | 4 A |
| Maximum power | 260 W |
| Maximum output voltage | 28 V |
| Minimum output voltage | 5 V |
| AC adapter output current | 5 A |
| Port 1 output power | 140 W |
| Port 2 output power | 140 W |
| Port 3 output power | 140 W |
| Port 4 output power | 140 W |
| Output current (5V) | 3 A |
| Output current (9V) | 3 A |
| Output current (12V) | 3 A |
| Output current (15V) | 3 A |
| Output current (20V) | 5 A |
| Power plug type | Type B |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 88 mm |
| Depth | 122 mm |
| Height | 35 mm |
| Weight | 563 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 188 mm |
| Package depth | 177 mm |
| Package height | 62 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 30 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Cables included | USB Type-C |
| Screws included | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, PSE, RoHS, UL, cULus |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 321 mm |
| Master (outer) case length | 217 mm |
| Master (outer) case height | 213 mm |
| Products per master (outer) case | 5 pc(s) |
