Power Hub 4 (IN)
Model Power Hub 4 (IN)Part no. O-PH-4-INEAN 7350113051820
66 specifications
- Power240 W
- Weight860 g
- ColourBlack
- Charger typeIndoor
- Input voltage200 V
- Width147 mm
Overview
- Power
- 240 W
- Weight
- 860 g
- Colour
- Black
- Charger type
- Indoor
- Input voltage
- 200 V
- Width
- 147 mm
- Brand
- Ochno
- Category
- Mobile Device Charger
- Model
- Power Hub 4 (IN)
- Part number
- O-PH-4-IN
- EAN / UPC
- 7350113051820
- Also known as
- Ochno Power Hub 4 (IN)
Specifications
66 specifications in 8 groups
Performance
| Specification | Value |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Mobile phone, Laptop, Smartphone, Tablet |
| Power source type | USB |
| USB Type-C ports quantity | 4 |
| Fast charging | Yes |
| Fast charging technology | GaN, Power Delivery 3.1, Programmable Power Supply (PPS) |
| Number of simultaneously connected devices (max) | 4 |
| Wi-Fi | Yes |
| Programmable power supply (PPS) | Yes |
| Operating principle | Contact |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.1 |
| USB Power Delivery up to | 140 W |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| MagSafe compatible | No |
| Power protection features | Over current, Overheating, Surge & inrush |
| Cooling fan | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| LED indicators | Network, Power, Status, USB, Wi-Fi |
| Plug and Play | Yes |
| Gallium nitride (GaN) transistors | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 200 V |
| Input frequency | 50/60 Hz |
| Input current | 2.5 A |
| Maximum power | 240 W |
| Maximum output voltage | 28 V |
| Port 1 output power | 140 W |
| Port 2 output power | 140 W |
| Port 3 output power | 140 W |
| Port 4 output power | 140 W |
| Output current (5V) | 3 A |
| Output current (9V) | 3 A |
| Output current (12V) | 3 A |
| Output current (15V) | 3 A |
| Output current (20V) | 5 A |
| Output current (24V) | 5 A |
| Port 1 output current | 5 A |
| Port 2 output current | 5 A |
| Port 3 output current | 5 A |
| Port 4 output current | 5 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 147 mm |
| Depth | 114 mm |
| Height | 36 mm |
| Weight | 860 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 156 mm |
| Package depth | 117 mm |
| Package height | 79 mm |
| Package weight | 1.21 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| AC adapter included | No |
| Cables included | AC |
| Included power plug types | EU |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CB, CE, ETL, REACH, RoHS, UKCA, WEEE |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8504.40.95 |
| Master (outer) case width | 375 mm |
| Master (outer) case length | 340 mm |
| Master (outer) case height | 185 mm |
| Master (outer) case gross weight | 15 kg |
| Products per master (outer) case | 12 pc(s) |
| Master (outer) case GTIN (EAN/UPC) | 7350113051820 |
| Country of origin | China |
| Warranty period | 3 year(s) |
