JUP43130E-EN
130W GaN USB-C® 4-Port Charger - EU
Model JUP43130E-ENEAN 24712795086694
46 specifications
- Power130 W
- Weight295 g
- ColourGrey, White
- Charger typeIndoor
- Width69 mm
- Operating temperature (T-T)0 - 30 °C
Overview
- Power
- 130 W
- Weight
- 295 g
- Colour
- Grey, White
- Charger type
- Indoor
- Width
- 69 mm
- Operating temperature (T-T)
- 0 - 30 °C
- Brand
- j5create
- Category
- Mobile Device Charger
- Model
- JUP43130E-EN
- Part number
- JUP43130E-EN
- EAN / UPC
- 24712795086694, 4712795086690
- Also known as
- j5create JUP43130E-EN - 130W GaN USB-C® 4-Port Charger - EU
Specifications
46 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Mobile computer, Mobile phone, Portable gaming console, Smartwatch, Tablet |
| Power source type | USB |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB Type-C ports quantity | 3 |
| Fast charging | Yes |
| Fast charging technology | Quick Charge 4 |
| Number of outputs | 4 outputs |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 130 W |
| Power protection features | Over current, Overcharge, Overheating |
| Compatibility | Smartphones: iPhone® 13, 13 mini, 13 pro, 13 pro max, 12 mini, 12, 12 Pro, 12 Pro Max, 11, 11 Pro, 11 Pro Max, XS Max, XR, XS, X, 8, 8 Plus Samsung® Galaxy™ Note10, Note10+, Note9, Note8, S22 Ultra, S22+, S22, S21 FE, S21 Ultra, S21, S20 FE, S20 Ultra, S20, S10, S10+, S10 Lite, S10 5G, S10e, S9+, S9 |
Design
| Specification | Value |
|---|---|
| Product colour | Grey, White |
| Housing material | Plastic |
| Gallium nitride (GaN) transistors | Yes |
Power
| Specification | Value |
|---|---|
| Maximum power | 130 W |
| Port 1 output power | 18 W |
| Port 2 output power | 20 W |
| Port 3 output power | 100 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 69 mm |
| Depth | 32 mm |
| Height | 87 mm |
| Weight | 295 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 155 mm |
| Package depth | 95 mm |
| Package height | 40 mm |
| Package weight | 375 g |
| Package type | Box |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 30 °C |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Logistics data
| Specification | Value |
|---|---|
| Export Control Classification Number (ECCN) | EAR99 |
| Master (outer) case width | 207 mm |
| Master (outer) case length | 224 mm |
| Master (outer) case height | 906 mm |
| Master (outer) case gross weight | 4.2 kg |
| Products per master (outer) case | 10 pc(s) |
| Shipping (inner) case width | 10.4 cm |
| Shipping (inner) case length | 2.15 m |
| Shipping (inner) case height | 18.5 cm |
| Shipping (inner) case gross weight | 2 kg |
| Products per shipping (inner) case | 5 pc(s) |
| Country of origin | China |
| Warranty period | 2 year(s) |
Other features
| Specification | Value |
|---|---|
| Packaging content | 1 - 130W GaN USB-C 4-Port Charger 1 - Quick Installation Guide (QIG) |
| Technical features | The first and the second USB-C® port provide up to 100W of power when used independently. The first and the second USB-C® port provide up to 65W of power when both ports are used. 【Dynamic Power Control of full load in 30mins : PD90W(PD45W+PD45W)】 The third USB-C® port provides up to 20W of power wh |
