USB power supply charger Dual USB-C, PD, PPS
30W, white
Model 31509CEAN 4043718336104
44 specifications
- Power30 W
- Weight38 g
- ColourWhite
- Charger typeIndoor
- Input voltage100 - 240 V
- Width38 mm
Overview
- Power
- 30 W
- Weight
- 38 g
- Colour
- White
- Charger type
- Indoor
- Input voltage
- 100 - 240 V
- Width
- 38 mm
- Brand
- InLine
- Category
- Mobile Device Charger
- Model
- 31509C
- Part number
- 31509C
- EAN / UPC
- 4043718336104
- Also known as
- InLine USB power supply charger Dual USB-C, PD, PPS, 30W, white
Specifications
44 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Universal |
| Power source type | AC |
| USB Type-C ports quantity | 2 |
| Wireless charging | No |
| Fast charging | Yes |
| Number of simultaneously connected devices (max) | 2 |
| Programmable power supply (PPS) | Yes |
| USB Power Delivery (USB PD) | Yes |
| Power protection features | Over current, Over voltage, Short circuit |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Gallium nitride (GaN) transistors | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Input current | 0.85 A |
| Maximum power | 30 W |
| Maximum output voltage | 20 V |
| Minimum output voltage | 5 V |
| AC adapter output current | 3 A |
| Port 1 output power | 30 W |
| Port 2 output power | 30 W |
| Output current (5V) | 3 A |
| Output current (9V) | 3 A |
| Output current (12V) | 2.5 A |
| Output current (15V) | 2 A |
| Output current (20V) | 1.5 A |
| Port 1 output current | 3 A |
| Port 2 output current | 3 A |
| Power consumption (no load) | 0.068 W |
| Average active efficiency | 84.77% (230V, 50Hz, USB-C1+USB-C2: 5. 0VDC/1.5A+5.0VDC/1.5A) |
| Efficiency at low load (10%) | Yes |
| Efficiency (@10 %) | 80.2% |
| Power plug type | Type C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 38 mm |
| Depth | 82 mm |
| Height | 16 mm |
| Weight | 38 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 85 mm |
| Package depth | 130 mm |
| Package height | 30 mm |
| Package volume | 200 cm³ |
| Package weight | 67 g |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 38 x 82 x 16 mm |
