ALTHEA23W65 3-Port
65W GaN USB PD Charger with Retractable USB-C Cable, USB-C x 1, USB-A x 1, QC 3.0, PPS, PD 3.0
Model ALTHEA23W65EAN 4015867245316
48 specifications
- Power65 W
- Weight150 g
- ColourWhite
- Charger typeIndoor
- Input voltage100 - 240 V
- Width98 mm
Overview
- Power
- 65 W
- Weight
- 150 g
- Colour
- White
- Charger type
- Indoor
- Input voltage
- 100 - 240 V
- Width
- 98 mm
- Brand
- Conceptronic
- Category
- Mobile Device Charger
- Model
- ALTHEA23W65
- Part number
- ALTHEA23W65
- EAN / UPC
- 4015867245316
- Also known as
- Conceptronic ALTHEA23W65 3-Port 65W GaN USB PD Charger with Retractable USB-C Cable, USB-C x 1, USB-A x 1, QC 3.0, PPS, PD 3.0
Specifications
48 specifications in 11 groups
Performance
| Specification | Value |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Smartphone, Tablet |
| Power source type | AC |
| USB Type-A ports quantity | 1 |
| USB Type-C ports quantity | 2 |
| Fast charging | Yes |
| Fast charging technology | Quick Charge 3.0, Power Delivery 3.0, Programmable Power Supply (PPS) |
| Number of simultaneously connected devices (max) | 3 |
| Programmable power supply (PPS) | Yes |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| Power protection features | Overload, Short circuit, Overheating |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Gallium nitride (GaN) transistors | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Input frequency | 50-60 Hz |
| Input current | 1.8 A |
| Maximum power | 65 W |
| Maximum output voltage | 20 V |
| Minimum output voltage | 5 V |
| Output current (5V) | 3 A |
| Output current (9V) | 3 A |
| Output current (12V) | 3 A |
| Output current (15V) | 3 A |
| Output current (20V) | 3.25 A |
| Port 1 output current | 3.65 A |
| Port 2 output current | 3.65 A |
| Port 3 output current | 3 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 98 mm |
| Depth | 45.8 mm |
| Height | 40 mm |
| Weight | 150 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 127 mm |
| Package depth | 75 mm |
| Package height | 43 mm |
| Package weight | 236 g |
| Package type | Box |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 35 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Storage relative humidity (H-H) | 5 - 90% |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Cables included | USB Type-C |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS, CE |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ErP |
Technical details
| Specification | Value |
|---|---|
| Pallet type | 800 x 1200 mm |
Logistics data
| Specification | Value |
|---|---|
| Customs product code (TARIC) | 8504408390 |
| Harmonized System (HS) code | 850440 |
| Country of origin | China |
