ALTHEA20B45 2-Port
45W GaN USB PD Charger, USB-C x 1, USB-A x 1, QC 3.0, PPS, PD 3.0
Model ALTHEA20B45EAN 4015867244050
52 specifications
- Power45 W
- Weight86.5 g
- ColourBlack
- Charger typeIndoor
- Input voltage100 - 240 V
- Width57 mm
Overview
- Power
- 45 W
- Weight
- 86.5 g
- Colour
- Black
- Charger type
- Indoor
- Input voltage
- 100 - 240 V
- Width
- 57 mm
- Brand
- Conceptronic
- Category
- Mobile Device Charger
- Model
- ALTHEA20B45
- Part number
- ALTHEA20B45
- EAN / UPC
- 4015867244050
- Also known as
- Conceptronic ALTHEA20B45 2-Port 45W GaN USB PD Charger, USB-C x 1, USB-A x 1, QC 3.0, PPS, PD 3.0
Specifications
52 specifications in 11 groups
Performance
| Specification | Value |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Universal |
| Power source type | AC |
| USB Type-A ports quantity | 1 |
| USB Type-C ports quantity | 1 |
| Wireless charging | No |
| Fast charging | Yes |
| Fast charging technology | Power Delivery 3.0, Programmable Power Supply (PPS), Quick Charge 3.0 |
| Number of simultaneously connected devices (max) | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| Power protection features | Overload, Overheating, Short circuit |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Gallium nitride (GaN) transistors | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Input current | 1.2 A |
| Maximum power | 45 W |
| Maximum output voltage | 20 V |
| Minimum output voltage | 5 V |
| Output current (5V) | 3 A |
| Output current (9V) | 3 A |
| Output current (12V) | 3 A |
| Output current (15V) | 3 A |
| Output current (20V) | 2.25 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 57 mm |
| Depth | 51 mm |
| Height | 32 mm |
| Weight | 86.5 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 127 mm |
| Package depth | 84 mm |
| Package height | 35 mm |
| Package weight | 134.5 g |
| Package type | Box |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Storage relative humidity (H-H) | 10 - 90% |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ErP |
Technical details
| Specification | Value |
|---|---|
| Master (outer) cases per pallet | 32 pc(s) |
Logistics data
| Specification | Value |
|---|---|
| Customs product code (TARIC) | 8504408390 |
| Pallet gross width | 120 cm |
| Pallet gross length | 80 cm |
| Pallet gross height | 159.2 cm |
| Master (outer) case width | 385 mm |
| Master (outer) case length | 272 mm |
| Master (outer) case height | 360 mm |
| Master (outer) case gross weight | 11.5 kg |
| Products per master (outer) case | 80 pc(s) |
| Country of origin | China |
