AISENS Gan 100W Charger, 2xUSB-C PD3.0 QC4.0 QC5.0, 1xUSB-A QC3.0, White

AISENS Gan 100W Charger, 2xUSB-C PD3.0 QC4.0 QC5.0, 1xUSB-A QC3.0, White

Model ASCH-100W3P008-WEAN 8436574708752

49 specifications

Power100 W
ColourWhite
Charger typeIndoor
Input voltage100 - 240 V
Width32 mm

See all specifications

Overview

Power: 100 W
Colour: White
Charger type: Indoor
Input voltage: 100 - 240 V
Width: 32 mm

Brand: AISENS
Category: Mobile Device Charger
Model: ASCH-100W3P008-W
Part number: ASCH-100W3P008-W
EAN / UPC: 8436574708752
Also known as: AISENS Gan 100W Charger, 2xUSB-C PD3.0 QC4.0 QC5.0, 1xUSB-A QC3.0, White

Specifications

49 specifications in 8 groups

Performance

Specification	Value
Charger type	Indoor
Charger compatibility	Universal
Power source type	AC
USB 2.0 ports quantity	1
USB Type-C ports quantity	2
Fast charging	Yes
Fast charging technology	Quick Charge 4, Quick Charge 5
Programmable power supply (PPS)	Yes
USB Power Delivery (USB PD)	Yes
USB Power Delivery revision	3.0
USB Power Delivery up to	100 W
Power protection features	Overload, Short circuit

Design

Specification	Value
Product colour	White
LED indicators	Yes
Gallium nitride (GaN) transistors	Yes

Power

Specification	Value
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Input current	1.5 A
Maximum power	100 W
Port 1 output power	65 W
Port 2 output power	30 W
Port 3 output power	18 W
Output current (5V)	3 A
Output current (9V)	3 A
Output current (12V)	3 A
Port 1 output current	5 A
Port 2 output current	5 A
Port 3 output current	3 A
Power plug type	Type C

Weight & dimensions

Specification	Value
Width	32 mm
Depth	55 mm
Height	73 mm

Packaging data

Specification	Value
Package width	100 mm
Package depth	95 mm
Package height	36 mm
Package volume	342 cm³
Package weight	252 g
Package type	Box

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
AC adapter included	Yes
Included power plug types	EU
Manual	Yes

Certificates

Specification	Value
Compliance certificates	RoHS

Logistics data

Specification	Value
Master (outer) case width	248 mm
Master (outer) case length	500 mm
Master (outer) case height	205 mm
Master (outer) case gross weight	12.6 kg
Master (outer) case volume	25420 cm³
Products per master (outer) case	50 pc(s)
