Deco X20(3-pack)
Model Deco X20(3-pack)Part no. Deco X20(3-pack) V1EAN 840030700330
47 specifications
- SpeedWi-Fi 5 (802.11ac)
- TypeMesh system
- ColourWhite
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- Built-in processorYes
- Ethernet LAN (RJ-45) ports2
Overview
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- Mesh system
- Colour
- White
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Built-in processor
- Yes
- Ethernet LAN (RJ-45) ports
- 2
- Brand
- TP-Link
- Category
- Mesh Wi-Fi System
- Model
- Deco X20(3-pack)
- Part number
- Deco X20(3-pack) V1
- EAN / UPC
- 840030700330, 6935364052416
- Also known as
- TP-Link AX1800 Whole Home Mesh Wi-Fi 6 System
Specifications
47 specifications in 10 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Product type | Mesh system |
| LED indicators | Power |
| Antenna type | Internal |
| Antennas quantity | 4 |
| Antenna direction type | Omni-directional |
| Maximum coverage | 540 m² |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (first band) | 1202 Mbit/s |
| WLAN data transfer rate (second band) | 574 Mbit/s |
| Number of guest networks (5 GHz) | 1 |
| Security algorithms | WPA-PSK, WPA2-PSK, WPA3 |
| Number of guest networks (2.4 GHz) | 1 |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor cores | 4 |
| Band steering | Yes |
| Quality of Service (QoS) support | Yes |
| Port forwarding | Yes |
| Firewall security | SPI |
| BeamForming | Yes |
| DHCP client | Yes |
| DHCP server | Yes |
| Mobile operating systems supported | Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3 |
| Parental control | Yes |
| Parental control features | Bedtime, Content filter, Custom profiles, Family time, Pause the Internet, Time controls, Weekly/monthly reports |
| MU-MIMO technology | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Power over Ethernet (PoE) | No |
| Ethernet WAN | Yes |
| DC-in jack | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 114 mm |
| Depth | 110 mm |
| Height | 114 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 369 mm |
| Package depth | 276.5 mm |
| Package height | 125 mm |
| Package weight | 2.66 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85171800 |
