Deco S7 (3-pack)
Model Deco S7 (3-pack)Part no. DECO S7(3-PACK)EAN 840030701665
58 specifications
- SpeedWi-Fi 5 (802.11ac)
- TypeMesh system
- ColourWhite, Black
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- Port forwardingYes
- Ethernet LAN (RJ-45) ports3
Overview
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- Mesh system
- Colour
- White, Black
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Port forwarding
- Yes
- Ethernet LAN (RJ-45) ports
- 3
- Brand
- TP-Link
- Category
- Mesh Wi-Fi System
- Model
- Deco S7 (3-pack)
- Part number
- DECO S7(3-PACK)
- EAN / UPC
- 840030701665, 1210002618106, 4897098681480, 6935364073022
- Also known as
- TP-Link AC1900 Whole Home Mesh Wi-Fi System, 3-Pack
Specifications
58 specifications in 11 groups
Design
| Specification | Value |
|---|---|
| Product colour | White, Black |
| Product type | Mesh system |
| LED indicators | Yes |
| Antenna type | Internal |
| Antennas quantity | 3 |
| Antenna direction type | Omni-directional |
| Transmit power | FCC: <30 dBm (2.4 GHz), <30 dBm (5 GHz) CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz) |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 1900 Mbit/s |
| WLAN data transfer rate (first band) | 600 Mbit/s |
| WLAN data transfer rate (second band) | 1300 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Number of guest networks (5 GHz) | 1 |
| Security algorithms | WPA, WPA2 |
| Number of guest networks (2.4 GHz) | 1 |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Dynamic IP | Yes |
| Static IP | Yes |
| IGMP proxy | Yes |
| IGMP snooping | Yes |
| Dynamic DNS (DDNS) | Yes |
| Guest access | Yes |
Features
| Specification | Value |
|---|---|
| Port forwarding | Yes |
| Firewall security | SPI |
| BeamForming | Yes |
| DHCP client | Yes |
| DHCP server | Yes |
| Mobile operating systems supported | Android, iOS |
| Universal Plug and Play (UPnP) | Yes |
| Parental control | Yes |
| MU-MIMO technology | Yes |
| MIMO | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 3 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 12 V |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS, CE |
| Certification | CE, FCC, RoHS, NCC, BSMI, JRF, JPA, VCCI |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 90.7 mm |
| Depth | 90.7 mm |
| Height | 162.3 mm |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 3 pc(s) |
| AC adapter included | Yes |
| Number of units included | 3 pc(s) |
| Ethernet cable | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 348 mm |
| Package depth | 213 mm |
| Package height | 160 mm |
| Package weight | 1.73 kg |
