Deco BE63
Model Deco BE63Part no. DECO BE63(2-PACK)
46 specifications
- SpeedWi-Fi 7 (802.11be)
- TypeMesh system
- ColourWhite
- Quality of Service (QoS) supportYes
- Ethernet LAN (RJ-45) ports4
- Operating temperature (T-T)0 - 40 °C
Overview
- Speed
- Wi-Fi 7 (802.11be)
- Type
- Mesh system
- Colour
- White
- Quality of Service (QoS) support
- Yes
- Ethernet LAN (RJ-45) ports
- 4
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- TP-Link
- Category
- Mesh Wi-Fi System
- Model
- Deco BE63
- Part numbers
- DECO BE63(2-PACK), DECO BE63(3-PACK), DECO BE63 3 PACK
- Also known as
- TP-Link Deco BE63 Tri-band (2.4 GHz / 5 GHz / 6 GHz) Wi-Fi 7 (802.11be) White 4 Internal
Specifications
46 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Product type | Mesh system |
| Antenna type | Internal |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) | 5188 Mbit/s |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 4324 Mbit/s |
| WLAN data transfer rate (third band) | 5188 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Number of guest networks (5 GHz) | 1 |
| Security algorithms | WPA, WPA2, WPA3 |
| Number of guest networks (2.4 GHz) | 1 |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Dynamic IP | Yes |
| Static IP | Yes |
| IGMP proxy | Yes |
| IGMP snooping | Yes |
| Tagged VLAN | Yes |
| Dynamic DNS (DDNS) | Yes |
| Guest access | Yes |
Features
| Specification | Value |
|---|---|
| Quality of Service (QoS) support | Yes |
| Port forwarding | Yes |
| DHCP client | Yes |
| DHCP server | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Parental control | Yes |
| Parental control features | Bedtime, Custom profiles, Family online time ranking, Family time, Off time, Pause the Internet, Professional content filter library, SafeSearch, Time rewards, Weekly/monthly reports, Youtube restriction |
| Works with Amazon Alexa | Yes |
| Firmware upgradeable via | Network |
| MU-MIMO technology | Yes |
| MIMO | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet WAN | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| DC-in jack | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 107.5 mm |
| Depth | 107.5 mm |
| Height | 176 mm |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 2 pc(s) |
