XRM570 Dual-band (2.4 GHz
5 GHz) Wi-Fi 5 (802.11ac) Black 4
Model XRM570Part no. XRM570-100NASEAN 606449143812
43 specifications
- Memory512 MB
- SpeedWi-Fi 5 (802.11ac)
- TypeTabletop router
- Weight801 g
- ColourBlack
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Overview
- Memory
- 512 MB
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- Tabletop router
- Weight
- 801 g
- Colour
- Black
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Brand
- NETGEAR
- Category
- Mesh Wi-Fi System
- Model
- XRM570
- Part numbers
- XRM570-100NAS, XRM570-100EUS
- EAN / UPC
- 606449143812, 606449143829, 10606449143826, 10606449143819
- Also known as
- NETGEAR XRM570 Dual-band (2.4 GHz / 5 GHz) Wi-Fi 5 (802.11ac) Black 4
Specifications
43 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Product type | Tabletop router |
| LED indicators | Power |
| Antennas quantity | 4 |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 2533 Mbit/s |
| WLAN data transfer rate (first band) | 400 Mbit/s |
| WLAN data transfer rate (second band) | 866 Mbit/s |
| WLAN data transfer rate (third band) | 866 Mbit/s |
| Networking standards | IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Security algorithms | 128-bit WEP, WEP, WPA, WPA2-PSK |
| VPN support | Secure remote access |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor cores | 2 |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| NAT functionality | Double firewall protection (SPI and NAT) |
| Mac operating systems supported | Yes |
| Universal Plug and Play (UPnP) | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet WAN | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| DC-in jack | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, CE, RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 321.9 mm |
| Depth | 55 mm |
| Height | 243.7 mm |
| Weight | 801 g |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 1 pc(s) |
| AC adapter included | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 275 mm |
| Package depth | 379 mm |
| Package height | 231 mm |
| Package weight | 2.89 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case gross weight | 3.6 kg |
| Master (outer) case height | 240 mm |
| Master (outer) case length | 402 mm |
| Master (outer) case width | 287 mm |
| Products per master (outer) case | 1 pc(s) |
