Mesh Set 1600 Dual-band (2.4 GHz
5 GHz) Wi-Fi 6 (802.11ax) Red, White 1 Internal
Model 1600Part no. 20003111EAN 4023125031113
28 specifications
- SpeedWi-Fi 6 (802.11ax)
- TypeMesh system
- Weight480 g
- ColourRed, White
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- WPS push buttonYes
Overview
- Speed
- Wi-Fi 6 (802.11ax)
- Type
- Mesh system
- Weight
- 480 g
- Colour
- Red, White
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- WPS push button
- Yes
- Brand
- FRITZ!
- Category
- Mesh Wi-Fi System
- Model
- 1600
- Part number
- 20003111
- EAN / UPC
- 4023125031113
- Also known as
- Mesh Set 1600 Dual-band (2.4 GHz / 5 GHz) Wi-Fi 6 (802.11ax) Red, White 1 Internal
Specifications
28 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Product colour | Red, White |
| Product type | Mesh system |
| LED indicators | System |
| Antenna type | Internal |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 3000 Mbit/s |
| WLAN data transfer rate (first band) | 2400 Mbit/s |
| WLAN data transfer rate (second band) | 600 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n |
| Security algorithms | WPA2, WPA3 |
| Guest access | Yes |
Features
| Specification | Value |
|---|---|
| WPS push button | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 6 W |
| AC input voltage | 230 V |
| AC input frequency | 50 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 80 mm |
| Height | 37 mm |
| Weight | 480 g |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 265 mm |
| Package depth | 183 mm |
| Package height | 85 mm |
| Package weight | 780 g |
