E30 mesh wi-fi system Dual-band (2.4 GHz
5 GHz) Wi-Fi 6 (802.11ax) White 1 Internal
Model E30EAN 790069800405
32 specifications
- SpeedWi-Fi 6 (802.11ax)
- ColourWhite
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- WPS push buttonYes
- Ethernet LAN (RJ-45) ports1
- Power consumption (typical)9.4 W
Overview
- Speed
- Wi-Fi 6 (802.11ax)
- Colour
- White
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- WPS push button
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Power consumption (typical)
- 9.4 W
- Brand
- D-Link
- Category
- Mesh Wi-Fi System
- Model
- E30
- Part number
- E30
- EAN / UPC
- 790069800405, 790069800740
- Also known as
- D-Link E30 mesh wi-fi system Dual-band (2.4 GHz / 5 GHz) Wi-Fi 6 (802.11ax) White 1 Internal
Specifications
32 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| LED indicators | Yes |
| Antenna type | Internal |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11b, 802.11a |
| WLAN data transfer rate (max) | 3000 Mbit/s |
| Networking standards | IEEE 802.11ax, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11k, IEEE 802.11v, IEEE 802.11a, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz |
| Security algorithms | WPA2, WPA, WPA3, WPS, WPS-PBC |
Features
| Specification | Value |
|---|---|
| WPS push button | Yes |
| Virtual assistant | Amazon Alexa & Google Assistant |
| Quality of Service (QoS) support | Yes |
| Parental control | Yes |
| Parental control features | Time controls |
| Works with Amazon Alexa | Yes |
| MU-MIMO technology | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 9.4 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC), CE, UL |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Indoor unit width | 7.45 cm |
| Indoor unit depth | 7.12 cm |
| Indoor unit height | 16.3 cm |
| Indoor unit weight | 208 g |
Packaging content
| Specification | Value |
|---|---|
| Ethernet cable | Yes |
| Quick installation guide | Yes |
