ZenWiFi XD5 (W-3-PK)
Model ZenWiFi XD5 (W-3-PK)Part no. 90IG0750-MO3B20EAN 4711081281177
32 specifications
- SpeedWi-Fi 6 (802.11ax)
- TypeMesh router
- ColourWhite
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
- Quality of Service (QoS) supportYes
- Ethernet LAN (RJ-45) ports2
Overview
- Speed
- Wi-Fi 6 (802.11ax)
- Type
- Mesh router
- Colour
- White
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Quality of Service (QoS) support
- Yes
- Ethernet LAN (RJ-45) ports
- 2
- Brand
- ASUS
- Category
- Mesh Wi-Fi System
- Model
- ZenWiFi XD5 (W-3-PK)
- Part number
- 90IG0750-MO3B20
- EAN / UPC
- 4711081281177, 4711387346129
- Also known as
- ASUS ZenWiFi XD5 (W-3-PK) Dual-band (2.4 GHz / 5 GHz) Wi-Fi 6 (802.11ax) White 2 Internal
Specifications
32 specifications in 6 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Product type | Mesh router |
| LED indicators | Power |
| Antenna type | Internal |
| Antennas quantity | 2 |
| Maximum coverage | 646.5 m² |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 2402 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Security algorithms | WPA, WPA2, WPA2-Enterprise, WPA3, WPS |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Static IP | Yes |
| IGMP snooping | Yes |
| Dynamic DNS (DDNS) | Yes |
| VPN support | VPN Client L2PT VPN Client OVPN VPN Client PPTP VPN Server IPSec VPN Server OVPN VPN Server PPTP |
Features
| Specification | Value |
|---|---|
| Quality of Service (QoS) support | Yes |
| DHCP server | Yes |
| Parental control | Yes |
| SSID Broadcast | Yes |
| MIMO | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet WAN | Yes |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 12 V |
| AC adapter output current | 1.5 A |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 3 pc(s) |
