ZenWiFi BN12 2er Pack
Model ZenWiFi BN12 2er PackPart no. 90IG0AQ0-MO9B20EAN 199291432352
56 specifications
- Memory2000 MB
- SpeedWi-Fi 8 (802.11bn)
- TypeMesh system
- Weight1.3 kg
- ColourWhite
- Mobile network generationNot supported
Overview
- Memory
- 2000 MB
- Speed
- Wi-Fi 8 (802.11bn)
- Type
- Mesh system
- Weight
- 1.3 kg
- Colour
- White
- Mobile network generation
- Not supported
- Brand
- ASUS
- Category
- Mesh Wi-Fi System
- Model
- ZenWiFi BN12 2er Pack
- Part number
- 90IG0AQ0-MO9B20
- EAN / UPC
- 199291432352, 4711636432351
- Also known as
- ASUS ZenWiFi BN12 2er Pack Tri-band (2.4 GHz / 5 GHz / 6 GHz) Wi-Fi 8 (802.11bn) White 5 Internal
Specifications
56 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Product type | Mesh system |
| LED indicators | Power |
| Antenna type | Internal |
| Antennas quantity | 8 |
| Maximum coverage | 650 m² |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard | Wi-Fi 8 (802.11bn) |
| Wi-Fi standards | Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), Wi-Fi 8 (802.11bn) |
| WLAN data transfer rate (max) | 11529 Mbit/s |
| WLAN data transfer rate (first band) | 1376 Mbit/s |
| WLAN data transfer rate (second band) | 5764 Mbit/s |
| WLAN data transfer rate (third band) | 11529 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g |
| Security algorithms | WPA3-Personal, WPA, WPA2, WPA2-Enterprise, WPS |
| IGMP snooping | Yes |
| Dynamic DNS (DDNS) | Yes |
| Guest access | Yes |
| Apps supported | ASUS Router |
| VPN support | Instant Guard, VPN Client L2TP, VPN Client Open VPN, VPN Client PPTP, VPN Client WireGuard, VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard, VPN Fusion |
Mobile network
| Specification | Value |
|---|---|
| Mobile network generation | Not supported |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor cores | 4 |
| Processor frequency | 2.6 GHz |
| Internal memory | 2000 MB |
| Flash memory | 256 MB |
| WPS push button | Yes |
| Quality of Service (QoS) support | Yes |
| Port forwarding | Yes |
| Firewall security | Firewall |
| DHCP server | Yes |
| Parental control | Yes |
| Parental control features | Content filter, Time controls, Time rewards |
| MU-MIMO technology | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 5 |
| Ethernet WAN | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 12 V |
| AC adapter output current | 5 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 173 mm |
| Depth | 88 mm |
| Height | 218 mm |
| Weight | 1.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 2 pc(s) |
| AC adapter included | Yes |
| Number of units included | 2 pc(s) |
| Ethernet cable | Yes |
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 418 mm |
| Package depth | 291 mm |
| Package height | 124 mm |
| Package weight | 4.2 kg |
