ZenWiFi BD4 Outdoor
Model ZenWiFi BD4 OutdoorPart no. 90IG09A0-M00B60EAN 197105611863
44 specifications
- Memory512 MB
- SpeedWi-Fi 7 (802.11be)
- TypeMesh router
- Weight1.04 kg
- ColourWhite
- Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Overview
- Memory
- 512 MB
- Speed
- Wi-Fi 7 (802.11be)
- Type
- Mesh router
- Weight
- 1.04 kg
- Colour
- White
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- Brand
- ASUS
- Category
- Mesh Wi-Fi System
- Model
- ZenWiFi BD4 Outdoor
- Part number
- 90IG09A0-M00B60
- EAN / UPC
- 197105611863, 4711387611869
- Also known as
- ASUS ZenWiFi BD4 Outdoor Dual-band (2.4 GHz / 5 GHz) Wi-Fi 7 (802.11be) White 2 Internal
Specifications
44 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Product type | Mesh router |
| LED indicators | Power |
| Antenna type | Internal |
| Antennas quantity | 2 |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) | 3600 Mbit/s |
| WLAN data transfer rate (first band) | 688 Mbit/s |
| WLAN data transfer rate (second band) | 2882 Mbit/s |
| Security algorithms | WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Personal, WPS |
| IGMP snooping | Yes |
| Dynamic DNS (DDNS) | Yes |
| VPN support | Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion |
Mobile network
| Specification | Value |
|---|---|
| Mobile network generation | Not supported |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor cores | 4 |
| Processor frequency | 1.5 GHz |
| Internal memory | 512 MB |
| Flash memory | 128 MB |
| Virtual assistant | Google Assistant |
| Quality of Service (QoS) support | Yes |
| Port forwarding | Yes |
| Firewall security | Firewall |
| BeamForming | Yes |
| DHCP server | Yes |
| Parental control | Yes |
| Parental control features | Content filter, SafeSearch, Time rewards |
| MU-MIMO technology | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet WAN | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 12 V |
| AC adapter output current | 2 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 106 mm |
| Depth | 106 mm |
| Height | 200 mm |
| Weight | 1.04 kg |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 1 pc(s) |
| Ethernet cable | Yes |
| Quick installation guide | Yes |
