ExpertWiFi EBM68
Model ExpertWiFi EBM68Part no. 90IG07V0-MA1A4VEAN 195553864480
37 specifications
- Memory1000 MB
- SpeedWi-Fi 6 (802.11ax)
- Weight808 g
- ColourWhite
- Built-in processorYes
- Ethernet LAN (RJ-45) ports4
Overview
- Memory
- 1000 MB
- Speed
- Wi-Fi 6 (802.11ax)
- Weight
- 808 g
- Colour
- White
- Built-in processor
- Yes
- Ethernet LAN (RJ-45) ports
- 4
- Brand
- ASUS
- Category
- Mesh Wi-Fi System
- Model
- ExpertWiFi EBM68
- Part numbers
- 90IG07V0-MA1A4V, 90IG07V0-MA1A6V
- EAN / UPC
- 195553864480, 195553864541
- Also known as
- ASUS ExpertWiFi EBM68 Tri-band (2.4 GHz / 5 GHz / 5 GHz) Wi-Fi 6 (802.11ax) White 4 Internal
Specifications
37 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| LED indicators | Power |
| Antenna type | Internal |
| Antennas quantity | 6 |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 4804 Mbit/s |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 2402 Mbit/s |
| WLAN data transfer rate (third band) | 4804 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g |
| Security algorithms | SSH, WPA, WPA2, WPA2-Enterprise, WPA3-Personal, WPS |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Guest access | Yes |
| VPN support | VPN Client L2PT VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion Support Surfshark |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor cores | 4 |
| Processor frequency | 1.7 GHz |
| Internal memory | 1000 MB |
| Flash memory | 128 MB |
| Firewall security | • Maximum Firewall Keyword Filter :64 • Maximum Firewall Network Service Filter :32 • Maximum Firewall URL Filter : 64 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet WAN | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 12 V |
| AC adapter output current | 3 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 167 mm |
| Depth | 77 mm |
| Height | 186 mm |
| Weight | 808 g |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 2 pc(s) |
| Ethernet cable | Yes |
| Quick installation guide | Yes |
