EBM68(1PK) – Expert Wifi
Model EBM68(1PK) – Expert WifiPart no. 90IG07V0-MO3A60EAN 4711081864608
51 specifications
- Memory1000 MB
- SpeedWi-Fi 6 (802.11ax)
- TypeMesh router
- Weight808 g
- ColourWhite
- Built-in processorYes
Overview
- Memory
- 1000 MB
- Speed
- Wi-Fi 6 (802.11ax)
- Type
- Mesh router
- Weight
- 808 g
- Colour
- White
- Built-in processor
- Yes
- Brand
- ASUS
- Category
- Mesh Wi-Fi System
- Model
- EBM68(1PK) – Expert Wifi
- Part number
- 90IG07V0-MO3A60
- EAN / UPC
- 4711081864608
- Also known as
- ASUS EBM68(1PK) – Expert Wifi Tri-band (2.4 GHz / 5 GHz / 5 GHz) Wi-Fi 6 (802.11ax) White 3 Internal
Specifications
51 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Product type | Mesh router |
| LED indicators | Power |
| Antenna type | Internal |
| Antennas quantity | 6 |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 4804 Mbit/s |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 2402 Mbit/s |
| WLAN data transfer rate (third band) | 4804 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Security algorithms | SSH, WPS |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Static IP | Yes |
| IGMP snooping | Yes |
| Dynamic DNS (DDNS) | Yes |
| Guest access | Yes |
| VPN support | VPN Client L2PT VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion Support Surfshark Support Nord VPN |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor frequency | 1.7 GHz |
| Internal memory | 1000 MB |
| Flash memory | 256 MB |
| Quality of Service (QoS) support | Yes |
| Port forwarding | Yes |
| Firewall security | Keyword Filter, Network Service Filter, URL Filter |
| BeamForming | Yes |
| DHCP server | Yes |
| SSID Broadcast | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 3 |
| Ethernet WAN | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 12 V |
| AC adapter output current | 3 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 167 mm |
| Depth | 77 mm |
| Height | 186 mm |
| Weight | 808 g |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 1 pc(s) |
| AC adapter included | Yes |
| Number of units included | 1 pc(s) |
| Ethernet cable | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 220 mm |
| Package depth | 262 mm |
| Package height | 147 mm |
| Package weight | 2.11 kg |
