BQ16 Tri-band (2.4 GHz
5 GHz / 6 GHz) Wi-Fi 7 (802.11be) White 3 Internal
Model BQ16Part no. 90IG08K0-MO3N4VEAN 4711387650912
40 specifications
- Memory2048 MB
- SpeedWi-Fi 7 (802.11be)
- Weight1.34 kg
- ColourWhite
- Ethernet LAN (RJ-45) ports3
- AC input voltage110 - 240 V
Overview
- Memory
- 2048 MB
- Speed
- Wi-Fi 7 (802.11be)
- Weight
- 1.34 kg
- Colour
- White
- Ethernet LAN (RJ-45) ports
- 3
- AC input voltage
- 110 - 240 V
- Brand
- ASUS
- Category
- Mesh Wi-Fi System
- Model
- BQ16
- Part number
- 90IG08K0-MO3N4V
- EAN / UPC
- 4711387650912
- Also known as
- ASUS BQ16 Tri-band (2.4 GHz / 5 GHz / 6 GHz) Wi-Fi 7 (802.11be) White 3 Internal
Specifications
40 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| LED indicators | Power |
| Antenna type | Internal |
| Antennas quantity | 12 |
| Reset button | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) | 11529 Mbit/s |
| WLAN data transfer rate (first band) | 1376 Mbit/s |
| WLAN data transfer rate (second band) | 5764 Mbit/s |
| WLAN data transfer rate (third band) | 11529 Mbit/s |
| Security algorithms | WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal, WPS |
| Guest access | Yes |
| VPN support | - VPN Client L2TP - VPN Client Open VPN - VPN Client PPTP - VPN Server IPSec - VPN Server Open VPN - VPN Server PPTP - VPN Fusion |
Features
| Specification | Value |
|---|---|
| Internal memory | 2048 MB |
| Flash memory | 256 MB |
| BeamForming | Yes |
| Parental control features | Content filter, Time controls, Time rewards |
| Operating modes | Wireless Router Mode, AiMesh Node Mode, Access Point Mode |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 3 |
| Ethernet WAN | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 19 V |
| AC adapter output current | 3.42 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 174.2 mm |
| Depth | 72 mm |
| Height | 214 mm |
| Weight | 1.34 kg |
Packaging content
| Specification | Value |
|---|---|
| Number of products included | 3 pc(s) |
| AC adapter included | Yes |
| Ethernet cable | Yes |
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 319 mm |
| Package depth | 368 mm |
| Package height | 187 mm |
| Package weight | 6.6 kg |
