TW1625LASC-B3PNR meeting room display
39.6 cm (15.6") 1920 x 1080 pixels LED Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a,
Model TW1625LASC-B3PNREAN 4948570125692
42 specifications
- Display39.6 cm (15.6")
- Resolution1920 x 1080 pixels
- ProcessorARM Rockchip
- OSAndroid
- Weight2 kg
- Housing colourBlack
Overview
- Display
- 39.6 cm (15.6")
- Resolution
- 1920 x 1080 pixels
- Processor
- ARM Rockchip
- OS
- Android
- Weight
- 2 kg
- Housing colour
- Black
- Brand
- iiyama
- Category
- Meeting Room Display
- Model
- TW1625LASC-B3PNR
- Part number
- TW1625LASC-B3PNR
- EAN / UPC
- 4948570125692
- Also known as
- iiyama TW1625LASC-B3PNR meeting room display 39.6 cm (15.6") 1920 x 1080 pixels LED Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a,
Specifications
42 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 39.6 cm (15.6") |
| Display resolution | 1920 x 1080 pixels |
| Display technology | LED |
| LED backlight | Yes |
| Pixel pitch | 0.1792 x 0.1792 mm |
| Response time | 20 ms |
| Display brightness | 390 cd/m² |
| Contrast ratio (typical) | 1000:1 |
| Touchscreen | Yes |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 10 |
| Fingerprint resistant | Yes |
Design
| Specification | Value |
|---|---|
| Housing colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 75 x 75 mm |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | ARM |
| Processor family | ARM Rockchip |
| Processor cores | 8 |
| Operating system installed | Android |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
Camera
| Specification | Value |
|---|---|
| Built-in camera | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ethernet LAN | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 397 mm |
| Depth | 28.5 mm |
| Height | 256 mm |
| Weight | 2 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 495 mm |
| Package depth | 75 mm |
| Package height | 305 mm |
| Package weight | 3 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
| Packaging content | AC adapter, interchangeable plugs (EU/UK), cable cover/wall mount |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ErP |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, EAC, REACH, RoHS, UKCA, WEEE |
