XBoard V7 series V655T

XBoard V7 series V655T

65" Microsoft Teams Rooms Interactive Touch Display

Model V655TEAN 6927433606248

70 specifications

Display165.1 cm (65")
Resolution3840 x 2160 pixels
ProcessorIntel® Core™ i5
Memory16 GB
Storage256000 MB
Weight35.5 kg

See all specifications

Overview

Display: 165.1 cm (65")
Resolution: 3840 x 2160 pixels
Processor: Intel® Core™ i5
Memory: 16 GB
Storage: 256000 MB
Weight: 35.5 kg

Brand: MAXHUB
Category: Meeting Room Display
Model: V655T
Part number: V655T
EAN / UPC: 6927433606248
Also known as: MAXHUB XBoard V7 series V655T 65" Microsoft Teams Rooms Interactive Touch Display

Specifications

70 specifications in 13 groups

Display

Specification	Value
Display diagonal	165.1 cm (65")
Display resolution	3840 x 2160 pixels
Display technology	IPS
LED backlight	Yes
LED backlighting type	Direct-LED
Pixel pitch	0.372 x 0.372 mm
Aspect ratio	16:9
Maximum refresh rate	60 Hz
Response time	8 ms
Viewing angle	178°
Display brightness	350 cd/m²
Contrast ratio (typical)	1200:1
Touchscreen	Yes
Touchscreen technology	Capacitive
Number of simultaneous touchpoints	50
Anti-glare surface	Yes

Design

Specification	Value
Housing colour	Black
VESA mounting	Yes
Ambient light sensor	Yes
Motion sensor	Yes

Performance

Specification	Value
Built-in processor	Yes
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor model	i5-1240P
RAM capacity	16 GB
Storage capacity	256000 MB

Audio

Specification	Value
Built-in microphone	Yes
Built-in speaker(s)	Yes
Number of speakers	2
Speaker power	40 W

Camera

Specification	Value
Built-in camera	Yes
Total megapixels	50 MP
Field of view (FOV) angle	99°
Camera privacy shutter	Yes
Second camera resolution	50 MP
Second camera field of view (FOV) angle	68°

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth	Yes
Bluetooth version	5.1
Ethernet LAN	Yes

Ports & interfaces

Specification	Value
USB port	Yes
USB port type	USB Type-A
Audio RCA inputs	1
Audio RCA outputs	1
HDMI input ports quantity	3
HDMI output ports quantity	2
RJ-45 ports quantity	2

Power

Specification	Value
Power source type	AC
Input voltage	100 - 240 V
Power consumption (average)	275 W
Power consumption (idle)	0.5 W
Power consumption (max)	350 W

Weight & dimensions

Specification	Value
Width	1488 mm
Depth	91 mm
Height	914 mm
Weight	35.5 kg

Packaging data

Specification	Value
Package width	1628 mm
Package depth	208 mm
Package height	1005 mm
Package weight	47.5 kg

Packaging content

Specification	Value
Cables included	AC, HDMI
Mounting kit	Yes
Number of stylus pens	2
Stylus pen	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C

Technical details

Specification	Value
Warranty period	3 year(s)
