MB65C-EDLA

MB65C-EDLA

Model MB65C-EDLAPart no. 1303287EAN 6938818323872

80 specifications

Display165.1 cm (65")
Resolution3840 x 2160 pixels
Memory8 GB
Storage64 MB
Weight38.5 kg
Housing colourBlack

See all specifications

Overview

Display: 165.1 cm (65")
Resolution: 3840 x 2160 pixels
Memory: 8 GB
Storage: 64 MB
Weight: 38.5 kg
Housing colour: Black

Brand: Yealink
Category: Meeting Room Display
Model: MB65C-EDLA
Part number: 1303287
EAN / UPC: 6938818323872
Also known as: Yealink MB65C-EDLA

Specifications

80 specifications in 12 groups

Display

Specification	Value
Display diagonal	165.1 cm (65")
Display resolution	3840 x 2160 pixels
Aspect ratio	16:9
Maximum refresh rate	60 Hz
Viewing angle	178°
Display brightness	350 cd/m²
Contrast ratio (typical)	1200:1
Touchscreen	Yes
Number of simultaneous touchpoints	20
Anti-glare surface	Yes

Design

Specification	Value
Housing colour	Black
VESA mounting	Yes
Panel mounting interface	600 x 400 mm
On/off switch	Yes

Performance

Specification	Value
Built-in processor	Yes
Processor cores	8
RAM capacity	8 GB
Storage capacity	64 MB
Windows operating systems supported	Yes

Audio

Specification	Value
Built-in microphone	Yes
Built-in speaker(s)	Yes
Speaker power	25 W
MEMS (Micro-Electro-Mechanical System) microphone	Yes
Number of microphones	8
Noise reduction	Yes
Echo cancellation	Yes
Automatic gain control	Yes
Audio beamforming	Yes

Camera

Specification	Value
Built-in camera	Yes
Maximum resolution	3840 x 2160 pixels
Total megapixels	50 MP
F-number (relative aperture)	1.56
Field of view (FOV) angle	98.2°
PTZ control	Yes
Camera shutter type	Electronic
Camera privacy shutter	Yes

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
MIMO	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Bluetooth	Yes
Bluetooth version	5.1
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Security algorithms	256-bit AES, AES, SRTP, TLS
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.1x
Quality of Service (QoS) support	Yes

Ports & interfaces

Specification	Value
USB port	Yes
USB port type	USB Type-A
Audio RCA inputs	1
Audio RCA outputs	1
HDMI input ports quantity	1
HDMI output ports quantity	1
RJ-45 ports quantity	2
USB 2.0 Type-A ports quantity	3
3.5 mm connector	Yes
HDMI ports quantity	2

Power

Specification	Value
Power source type	AC
Input voltage	100 - 240 V
Power consumption (average)	140 W
Power consumption (max)	183 W
USB output current	0.5 A
USB output voltage	5 V

Weight & dimensions

Specification	Value
Width	1484 mm
Depth	83.4 mm
Height	957.7 mm
Weight	38.5 kg

Packaging data

Specification	Value
Package width	1615 mm
Package depth	230 mm
Package height	1054 mm
Package weight	46.6 kg
Package type	Box

Packaging content

Specification	Value
Cables included	AC, LAN (RJ-45)
Quick start guide	Yes
Number of stylus pens	4
Packaging content	- 1 x 3m AC power cable - 1 x 3m CAT5E network cable - 4 x Stylus pens - 3 x Cable ties - 1 x Quick Start Guide
Stylus pen	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C
