Room Booking System
10.1" RBS Panel
Model VK430Part no. VK430-ATEAN 672792013393
31 specifications
- Display25.6 cm (10.1")
- Resolution1280 x 800 pixels
- Weight900 g
- Housing materialPlastic
- Built-in speaker(s)No
- RJ-45 ports quantity1
Overview
- Display
- 25.6 cm (10.1")
- Resolution
- 1280 x 800 pixels
- Weight
- 900 g
- Housing material
- Plastic
- Built-in speaker(s)
- No
- RJ-45 ports quantity
- 1
- Brand
- ATEN
- Category
- Meeting Room Display
- Model
- VK430
- Part number
- VK430-AT
- EAN / UPC
- 672792013393, 4710469341588
- Also known as
- ATEN Room Booking System - 10.1" RBS Panel
Specifications
31 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1280 x 800 pixels |
| Aspect ratio | 16:10 |
| Touchscreen technology | Capacitive |
Design
| Specification | Value |
|---|---|
| Housing material | Plastic |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| RJ-45 ports quantity | 1 |
| USB 2.0 Type-A ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC, PoE |
| Input voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 177.8 mm |
| Depth | 263 mm |
| Height | 37.2 mm |
| Weight | 900 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 360 mm |
| Package depth | 234 mm |
| Package height | 52 mm |
| Package weight | 1.24 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 55 °C |
Technical details
| Specification | Value |
|---|---|
| Master (outer) case volume | 28033.68 cm³ |
| Package volume | 4530.7 cm³ |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case gross weight | 6.7 kg |
| Master (outer) case height | 263 mm |
| Master (outer) case length | 370 mm |
| Master (outer) case width | 288 mm |
