Varifocal Lens, Megapixel, 2.7-10mm
Model CAS-1300EAN 4015867158593
20 specifications Checked today
- Weight85 g
- ColourBlack
- Component forIP Camera
- Operating temperature (T-T)-10 - 50 °C
- Diameter3.99 cm
Overview
- Weight
- 85 g
- Colour
- Black
- Component for
- IP Camera
- Operating temperature (T-T)
- -10 - 50 °C
- Diameter
- 3.99 cm
- Brand
- LevelOne
- Category
- Lens
- Model
- CAS-1300
- Part number
- CAS-1300
- EAN / UPC
- 4015867158593
- Also known as
- LevelOne Varifocal Lens, Megapixel, 2.7-10mm
Specifications
20 specifications in 6 groups
Lens system
| Specification | Value |
|---|---|
| Component for | IP Camera |
| Lens viewing angle, horizontal | 95.4° |
| Aperture range (F-F) | 1.4 - 360 |
| Lens viewing angle, vertical | 71.3° |
| Lens viewing angle, diagonal | 118.1 - 40.6° |
| Focal length range | 2.8 - 8.5 mm |
| Lens mount interface | CS mount |
| Minimum aperture number | 360 |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Sensor type | CCD |
Performance
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 50 °C |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 90021100 |
Weight & dimensions
| Specification | Value |
|---|---|
| Diameter | 3.99 cm |
| Length | 57.1 mm |
| Weight | 85 g |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 130 mm |
| Package height | 53 mm |
| Package weight | 170 g |
| Package width | 75 mm |
