RF 15-30 mm f4.5-6.3 IS STM
Model RF 15-30 mm f4.5-6.3 IS STM
61 specifications Checked today
- Weight390 g
- ColourBlack
- Component forMILC
- AF actuatorSTM
- Diameter7.66 cm
Overview
- Weight
- 390 g
- Colour
- Black
- Component for
- MILC
- AF actuator
- STM
- Diameter
- 7.66 cm
- Brand
- Canon
- Category
- Lens
- Model
- RF 15-30 mm f4.5-6.3 IS STM
- Also known as
- Canon RF 15-30 mm f4.5-6.3 IS STM MILC Ultra-wide lens Black
Specifications
61 specifications in 7 groups
Lens system
| Specification | Value |
|---|---|
| Component for | MILC |
| Lens structure (elements/groups) | 13/11 |
| Lens type | Ultra-wide lens |
| Lens viewing angle, horizontal | 100° 25' - 61°55' |
| Lens viewing angle, vertical | 77° 20' - 43° 35' |
| Lens viewing angle, diagonal | 110° 30'- 71° 35' |
| Focal length range | 15 - 30 mm |
| Control ring | Yes |
| Image sensor format | Full frame |
| Lens mount interface | Canon RF |
| Maximum aperture number | 6.3 |
| Minimum aperture number | 4.5 |
| Number of aspheric elements | 1 |
| Number of diaphragm blades | 7 |
| Image stabilizer | Yes |
| Image stabilizer type | Optical Image Stabilization (OIS) |
| Image stabilizer number of stops | 5.5 |
| Image stabilizer number of stops (OIS) | 5.5 |
| Image stabilizer number of stops (IBIS x OIS) | 7 |
Performance
| Specification | Value |
|---|---|
| AF actuator | STM |
| Auto focus | Yes |
| Camera brands compatibility | Canon |
| Distance information | Yes |
| Lens coating features | Super Spectra Coating (SSC) |
| Lens colour | Black |
| Manual focus | Yes |
| Maximum magnification | 2x |
| Number of Ultra-low Dispersion (UD) elements | 2 |
| Lens hood | Yes |
| Lens hood model | EW-73E |
| Compatible products | Objektivrückdeckel RF, Filterhalter IV (67mm), Canon Schutzfilter (67mm), Canon PL-C B Zirkularpolfiter (67mm), Objektivtasche LP1116. Streulichblende nicht im Lieferumfang enthalten. |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Waterproof | No |
| Dustproof | No |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case gross weight | 4.11 kg |
| Master (outer) case height | 237 mm |
| Master (outer) case length | 386 mm |
| Master (outer) case width | 263 mm |
| Pallet gross height | 131.5 cm |
| Pallet gross length | 120 cm |
| Pallet gross weight | 199.9 kg |
| Pallet gross width | 80 cm |
| Products per master (outer) case | 6 pc(s) |
| Products per pallet | 180 pc(s) |
| Quantity per pack | 1 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet layer | 6 pc(s) |
| Products per pallet layer | 36 pc(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Diameter | 7.66 cm |
| Filter size | 67 mm |
| Length | 88.8 mm |
| Weight | 390 g |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 122 mm |
| Package height | 183 mm |
| Package weight | 577.5 g |
| Package width | 122 mm |
Packaging content
| Specification | Value |
|---|---|
| Lens cap included | Yes |
| Lens cap model | E-67 II |
| Rear lens cap included | Yes |
| Rear lens cap model | RF |
| User guide | Yes |
