O-L-03X7133-EU laptop dock/port replicator Wired Thunderbolt 3 Black
Model O-L-03X7133-EUEAN 5711603062474
27 specifications
- ConnectivityWired
- Weight1.1 kg
- ColourBlack
- Ethernet LANYes
- Power source typeAC
- Operating temperature (T-T)5 - 40 °C
Overview
- Connectivity
- Wired
- Weight
- 1.1 kg
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC
- Operating temperature (T-T)
- 5 - 40 °C
- Brand
- T1A
- Category
- Laptop Docks & Port Replicators
- Model
- O-L-03X7133-EU
- Part number
- O-L-03X7133-EU
- EAN / UPC
- 5711603062474
- Also known as
- T1A O-L-03X7133-EU laptop dock/port replicator Wired Thunderbolt 3 Black
Specifications
27 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | Thunderbolt 3 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 2 |
| Thunderbolt 3 ports quantity | 2 |
| Microphone in | Yes |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 268 mm |
| Depth | 165 mm |
| Height | 90 mm |
| Weight | 1.1 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
