StarTech.com Travel Docking Station for Laptops - HDMI or VGA - USB 3.0
StarTech.com

Travel Docking Station for Laptops - HDMI or VGA - USB 3.0

Model USB3SMDOCKHVEAN 650308582816

50 specifications
  • ConnectivityWired
  • Weight82 g
  • ColourBlack
  • Ethernet LANYes
  • Power source typeUSB
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Connectivity
Wired
Weight
82 g
Colour
Black
Ethernet LAN
Yes
Power source type
USB
Operating temperature (T-T)
0 - 40 °C
Brand
StarTech.com
Model
USB3SMDOCKHV
Part number
USB3SMDOCKHV
EAN / UPC
650308582816, 012305135233, 065030858281, 4058829180461 +1 more
Also known as
StarTech.com Travel Docking Station for Laptops - HDMI or VGA - USB 3.0

Specifications

50 specifications in 12 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-A
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
HDMI ports quantity1
VGA (D-Sub) ports quantity1
Microphone inNo
Headphone outputs0
DC-in jackNo

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Auto MDI/MDI-XYes
Full duplexYes

Performance

Product colourBlack
Card reader integratedNo
Data transfer rate5 Gbit/s
Maximum digital resolution2048 x 1152 pixels
Housing materialPlastic
LED indicatorsActivity, Link
UASP supportYes
Brand compatibilityAny brand
CertificationCE, FCC, REACH

Power

Power source typeUSB
Wireless chargingNo

Software

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterpri
Mac operating systems supportedMac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)0 - 90%

Weight & dimensions

Width55 mm
Depth125 mm
Height17 mm
Weight82 g

Packaging data

Package width167 mm
Package depth143 mm
Package height43 mm
Package weight192 g

Packaging content

Drivers includedYes
ManualYes

Technical details

Compliance certificatesRoHS

Logistics data

Harmonized System (HS) code84733020
Master (outer) case height309 mm
Master (outer) case length448 mm
Master (outer) case width346 mm
Products per master (outer) case40 pc(s)

Other features

Cable length0.093 m
ChipsetDisplayLink - DL-3700
