StarTech.com Thunderbolt 3 PCIe Expansion Chassis, External Enclosure with One PCI Express Slot, PCIe Box for Laptops/Desktops/All-In-Ones, 5K/4K Output Via TB3
StarTech.com

Thunderbolt 3 PCIe Expansion Chassis, External Enclosure with One PCI Express Slot, PCIe Box for Laptops/Desktops/All-In-Ones, 5K/4K Output Via TB3

Model TB31PCIEX16EAN 065030868440

57 specifications
  • ConnectivityWired
  • Noise24.55 dB
  • Weight1.6 kg
  • ColourBlack
  • Ethernet LANNo
  • Built-in fanYes
See all specifications

Overview

Connectivity
Wired
Noise
24.55 dB
Weight
1.6 kg
Colour
Black
Ethernet LAN
No
Built-in fan
Yes
Brand
StarTech.com
Model
TB31PCIEX16
Part number
TB31PCIEX16
EAN / UPC
065030868440
Also known as
StarTech.com Thunderbolt 3 PCIe Expansion Chassis, External Enclosure with One PCI Express Slot, PCIe Box for Laptops/Desktops/All-In-Ones, 5K/4K Output Via TB3

Specifications

57 specifications in 14 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceThunderbolt 3
USB 2.0 ports quantity0
HDMI ports quantity0
DisplayPorts quantity1
Thunderbolt 3 ports quantity2
DC-in jackYes

Network

Ethernet LANNo
Ethernet LAN (RJ-45) ports0

Performance

Product colourBlack
Card reader integratedNo
Data transfer rate40 Gbit/s
Housing materialAluminium, Steel
LED indicatorsPower
Rubber feetYes

Cooling

Built-in fanYes
Number of fans1 fan(s)
Bearing typeSleeve bearing
Fan diameter6 cm
Noise level24.55 dB
Maximum airflow14.06 cfm

Power

Power source typeDC
AC input voltage100 - 240 V
Input current2 A
Output current5.417 A
Output voltage12 V
Power consumption (typical)65 W
Power plug typeType N
Compatible power plug typesAU, EU, JP, UK, US
Wireless chargingNo

Software

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Ent
Mac compatibilityYes
Mac operating systems supportedMac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)20 - 80%

Sustainability

Sustainability complianceYes

Weight & dimensions

Width142 mm
Depth280 mm
Height82 mm
Weight1.6 kg

Packaging data

Package width471 mm
Package depth239 mm
Package height94 mm
Package weight3.1 kg

Packaging content

AC adapter includedYes
Cables includedThunderbolt
Quick start guideYes

Technical details

Compliance certificatesCE, RoHS

Logistics data

Harmonized System (HS) code84733020
Master (outer) case height331 mm
Master (outer) case length384 mm
Master (outer) case width467 mm
Products per master (outer) case3 pc(s)

Other features

Cable length0.5 m
ChipsetIntel - Alpine Ridge DSL6540
Maximum port bandwidth3.94 GB/s
