StarTech.com USB-C Multiport Adapter - HDMI/VGA - 4K
StarTech.com

USB-C Multiport Adapter - HDMI/VGA - 4K

60Hz - 3-Port USB Hub - 100W Power Delivery Pass-Through - GbE - Travel Mini Docking Station w/ Charging -

Model DKT31CVHPD3EAN 065030891998

56 specifications
  • ConnectivityWired
  • Weight130 g
  • ColourGrey
  • Ethernet LANYes
  • Power consumption (typical)16 W
  • Mobile operating systems supportedAndroid
See all specifications

Overview

Connectivity
Wired
Weight
130 g
Colour
Grey
Ethernet LAN
Yes
Power consumption (typical)
16 W
Mobile operating systems supported
Android
Brand
StarTech.com
Model
DKT31CVHPD3
Part number
DKT31CVHPD3
EAN / UPC
065030891998
Also known as
StarTech.com USB-C Multiport Adapter - HDMI/VGA - 4K 60Hz - 3-Port USB Hub - 100W Power Delivery Pass-Through - GbE - Travel Mini Docking Station w/ Charging -

Specifications

56 specifications in 13 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB Power Delivery (USB PD)Yes
USB Power Delivery up to100 W
HDMI ports quantity1
HDMI version2.0b
VGA (D-Sub) ports quantity1
Microphone inNo
Headphone outputs0
DC-in jackNo

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Full duplexYes

Performance

Product colourGrey
Card reader integratedNo
Data transfer rate10 Gbit/s
HD type4K Ultra HD
Maximum digital resolution4096 x 2160 pixels
Maximum analog resolution1920 x 1200 pixels
Maximum refresh rate60 Hz
Housing materialPlastic
LED indicatorsYes
UASP supportYes

Power

Power consumption (typical)16 W
USB cable length0.32 m
Wireless chargingNo

Software

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Ent
Mac operating systems supportedMac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Linux operating systems supportedUbuntu 18.04 LTS, Ubuntu 20.04 LTS
Mobile operating systems supportedAndroid
Other operating systems supportedChromeOS

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 55 °C
Operating relative humidity (H-H)0 - 85%

Sustainability

Sustainability complianceYes

Weight & dimensions

Width64 mm
Depth124 mm
Height25 mm
Weight130 g

Packaging data

Package width143 mm
Package depth173 mm
Package height33 mm
Package weight154 g

Packaging content

Quick start guideYes

Technical details

Compliance certificatesCE, RoHS

Logistics data

Master (outer) case height440 mm
Master (outer) case length331 mm
Master (outer) case width473 mm
Products per master (outer) case70 pc(s)

Other features

ChipsetRealtek - RTD2142, Realtek - RTL8153B, VIA - VL822-Q8, VIA - VL103
