StarTech.com USB C Dock - Dual Monitor HDMI & DisplayPort 4K
StarTech.com

USB C Dock - Dual Monitor HDMI & DisplayPort 4K

30Hz - USB Type-C Laptop Docking Station 60W Power Delivery, SD, 4-port USB-A 3.0 Hub, GbE, Audio -

Model DK30CHDPPDUEEAN 065030872683

61 specifications
  • ConnectivityWired
  • Weight261 g
  • ColourBlack, Silver
  • Ethernet LANYes
  • Power source typeAC
  • Operating temperature (T-T)0 - 60 °C
See all specifications

Overview

Connectivity
Wired
Weight
261 g
Colour
Black, Silver
Ethernet LAN
Yes
Power source type
AC
Operating temperature (T-T)
0 - 60 °C
Brand
StarTech.com
Model
DK30CHDPPDUE
Part number
DK30CHDPPDUE
EAN / UPC
065030872683
Also known as
StarTech.com USB C Dock - Dual Monitor HDMI & DisplayPort 4K 30Hz - USB Type-C Laptop Docking Station 60W Power Delivery, SD, 4-port USB-A 3.0 Hub, GbE, Audio -

Specifications

61 specifications in 12 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB Power Delivery (USB PD)Yes
USB Power Delivery up to60 W
HDMI ports quantity1
DisplayPorts quantity1
Microphone inNo
Combo headphone/mic portYes
Headphone outputs1
Headphone connectivity3.5 mm
DC-in jackYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Auto MDI/MDI-XYes
Full duplexYes

Performance

Product colourBlack, Silver
Card reader integratedYes
Compatible memory cardsMMC, MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC
Data transfer rate5 Gbit/s
Maximum digital resolution3840 x 2160 pixels
Number of displays supported2
On/off switchYes
Housing materialPlastic
UASP supportYes
CertificationCE, FCC, REACH

Power

Power source typeAC
AC input voltage100 - 240 V
Input current2 A
Output current5 A
Output voltage20 V
Compatible power plug typesEU, UK

Software

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home
Mac compatibilityYes
Mac operating systems supportedMac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 13.0 Ventura
Other operating systems supportedChromeOS

Operational conditions

Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 95%

Weight & dimensions

Width80 mm
Depth220 mm
Height25 mm
Weight261 g

Packaging data

Package width155 mm
Package depth270 mm
Package height90 mm
Package weight1.3 kg

Packaging content

AC adapter includedYes
Cables includedUSB
ManualYes

Technical details

Compliance certificatesRoHS

Logistics data

Harmonized System (HS) code84733020
Master (outer) case height302 mm
Master (outer) case length335 mm
Master (outer) case width280 mm
Products per master (outer) case6 pc(s)

Other features

Cable length1 m
ChipsetDisplayLink - DL-5700, Genesys Logic - GL3215, VIA Labs - VL813, Texas Instruments - TPS65983
