USB-C to HDMI Multiport Adapter
140W PD Charging, 4K 60Hz, 3-Port USB 10Gbps Hub, SD Card Slot, 2.5GbE, Mini Dock for MacBook / Dell / Thinkpad /
Model 177B-USBC-MULTIPORTEAN 065030904162
53 specifications
- ConnectivityWired
- Weight100 g
- ColourGrey
- Ethernet LANYes
- Power source typeUSB
- Operating temperature (T-T)-10 - 45 °C
Overview
- Connectivity
- Wired
- Weight
- 100 g
- Colour
- Grey
- Ethernet LAN
- Yes
- Power source type
- USB
- Operating temperature (T-T)
- -10 - 45 °C
- Brand
- StarTech.com
- Category
- Laptop Docks & Port Replicators
- Model
- 177B-USBC-MULTIPORT
- Part number
- 177B-USBC-MULTIPORT
- EAN / UPC
- 065030904162
- Also known as
- StarTech.com USB-C to HDMI Multiport Adapter, 140W PD Charging, 4K 60Hz, 3-Port USB 10Gbps Hub, SD Card Slot, 2.5GbE, Mini Dock for MacBook / Dell / Thinkpad /
Specifications
53 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.2 |
| USB Power Delivery up to | 140 W |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Microphone in | No |
| Headphone outputs | 0 |
| USB Type-C DisplayPort Alternate Mode | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Full duplex | Yes |
Performance
| Specification | Value |
|---|---|
| Product colour | Grey |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| Data transfer rate | 10 Gbit/s |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Number of displays supported | 1 |
| Housing material | Aluminium, Plastic |
| Mean time between failures (MTBF) | 28434 h |
| UASP support | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
| Power consumption (max) | 20 W |
| USB cable length | 0.12 m |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterp |
| Mac operating systems supported | Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia, Mac OS 26 Tahoe |
| Linux operating systems supported | Yes |
| Mobile operating systems supported | iPadOS, iOS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 45 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 50 mm |
| Depth | 125 mm |
| Height | 15 mm |
| Weight | 100 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 190 mm |
| Package depth | 57 mm |
| Package height | 19 mm |
| Package weight | 141 g |
Packaging content
| Specification | Value |
|---|---|
| User guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS, CE |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case height | 260 mm |
| Master (outer) case length | 205 mm |
| Master (outer) case width | 425 mm |
| Products per master (outer) case | 80 pc(s) |
Other features
| Specification | Value |
|---|---|
| Chipset | VIA - VL600, VIA - VL109, VIA - VL822, Realtek - RTL8156BG, Genesys Logic - GL3224 |
