Docking Station USB-C
Model OSDOCK-USBCEAN 5056006165026
50 specifications
- ConnectivityDocking
- Weight500 g
- ColourBlack
- Ethernet LANYes
- Power source typeUSB
- Operating temperature (T-T)0 - 35 °C
Overview
- Connectivity
- Docking
- Weight
- 500 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- USB
- Operating temperature (T-T)
- 0 - 35 °C
- Brand
- Origin Storage
- Category
- Laptop Docks & Port Replicators
- Model
- OSDOCK-USBC
- Part number
- OSDOCK-USBC
- EAN / UPC
- 5056006165026
- Also known as
- Origin Storage Docking Station USB-C
Specifications
50 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Docking |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 85 W |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 2 |
| Microphone in | No |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Number of displays supported | 3 |
| On/off switch | Yes |
| Charging function | Yes |
| Housing material | Plastic |
| LED indicators | Light |
| Rubber feet | Yes |
| Country of origin | Taiwan |
| Brand compatibility | Any brand |
| Certification | CE, FCC |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
| Power connector | USB Type-C |
| USB cable length | 1 m |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 190 mm |
| Depth | 85.3 mm |
| Height | 27 mm |
| Weight | 500 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 250 mm |
| Package depth | 115 mm |
| Package height | 127 mm |
| Package weight | 770 g |
Packaging content
| Specification | Value |
|---|---|
| Mounting brackets included | No |
| Warranty card | Yes |
| AC adapter included | Yes |
| Cables included | AC, USB Type-C |
| Drivers included | Yes |
| Low-profile bracket | No |
| Manual | Yes |
| Quick start guide | Yes |
| User guide | Yes |
| Stand included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Warranty period | 1 year(s) |
