USB-C Mini Dock
Model USB-C Mini DockPart no. 40AU0065SAEAN 5715063024164
37 specifications
- ConnectivityWired
- Weight156 g
- ColourGrey
- Ethernet LANYes
- Power source typeAC
- Windows operating systems supportedWindows 10
Overview
- Connectivity
- Wired
- Weight
- 156 g
- Colour
- Grey
- Ethernet LAN
- Yes
- Power source type
- AC
- Windows operating systems supported
- Windows 10
- Brand
- Lenovo
- Category
- Laptop Docks & Port Replicators
- Model
- USB-C Mini Dock
- Part numbers
- 40AU0065SA, 40AU0065EU, 40AU0065DK, 40AU0065CH, 40AU0065IT, 40AU0065AU
- EAN / UPC
- 5715063024164, 193386926139, 5715328151765, 193386926092 +5 more
- Also known as
- Lenovo USB-C Mini Dock Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Grey
Specifications
37 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| VGA (D-Sub) ports quantity | 1 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Grey |
| Card reader integrated | No |
| Certification | CB, BSMI, SII, CU, Ukraine, Kvalitet, LOA, NOM, cULus, FCC, ICES, CE, RCM, VCCI, KCC, EAC |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power supply | 65 W |
| Wireless charging | No |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 180 mm |
| Depth | 53 mm |
| Height | 17 mm |
| Weight | 156 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 215 mm |
| Package depth | 210 mm |
| Package height | 65 mm |
| Package weight | 565 g |
Packaging content
| Specification | Value |
|---|---|
| Warranty card | Yes |
| AC adapter included | Yes |
| User guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
