SD3650 Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-B Black
Model SD3650Part no. 4Z91B78860EAN 195348684934
57 specifications
- ConnectivityWired
- ColourBlack
- Ethernet LANYes
- Power source typeDC
- Operating temperature (T-T)10 - 40 °C
- Width198 mm
Overview
- Connectivity
- Wired
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- DC
- Operating temperature (T-T)
- 10 - 40 °C
- Width
- 198 mm
- Brand
- Lenovo
- Category
- Laptop Docks & Port Replicators
- Model
- SD3650
- Part number
- 4Z91B78860
- EAN / UPC
- 195348684934, 5054444396392
- Also known as
- Lenovo SD3650 Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-B Black
Specifications
57 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.3 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
| HDCP | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Data transfer rate | 5 Gbit/s |
| HD type | 2K Ultra HD |
| Maximum digital resolution | 2560 x 1600 pixels |
| Maximum refresh rate | 60 Hz |
| Number of displays supported | 2 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| LED indicators | Yes |
| Plug and Play | Yes |
| Country of origin | Taiwan |
| Certification | FCC, CE, C-Tick, REACH, WEEE, RoHS |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 0.8 A |
| Output current | 4 A |
| Output voltage | 5 V |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 40 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 198 mm |
| Depth | 80 mm |
| Height | 34 mm |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 249 mm |
| Package depth | 165 mm |
| Package height | 84 mm |
| Package weight | 860 g |
Packaging content
| Specification | Value |
|---|---|
| Warranty card | Yes |
| AC adapter included | Yes |
| Cables included | USB |
| Quick start guide | Yes |
Other features
| Specification | Value |
|---|---|
| Compatible operating systems | macOS 10.14 or above; Windows 7 or above |
| USB ports quantity | 6 |
