GX90T77924 laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Grey
Model GX90T77924EAN 193268856752
28 specifications
- ConnectivityWired
- Weight122 g
- ColourGrey
- Power supply typeUSB
- Windows operating systems supportedWindows 10
- Operating temperature (T-T)-5 - 40 °C
Overview
- Connectivity
- Wired
- Weight
- 122 g
- Colour
- Grey
- Power supply type
- USB
- Windows operating systems supported
- Windows 10
- Operating temperature (T-T)
- -5 - 40 °C
- Brand
- Lenovo
- Category
- Laptop Docks & Port Replicators
- Model
- GX90T77924
- Part number
- GX90T77924
- EAN / UPC
- 193268856752, 1932688567522
- Also known as
- Lenovo GX90T77924 laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Grey
Specifications
28 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
Performance
| Specification | Value |
|---|---|
| Product colour | Grey |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Hub interfaces | HDMI, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Plug and Play | Yes |
| Certification | CB, FCC, ICES, CE, RCM, VCCI, BSMI, Ukraine, EAC, KC |
Power
| Specification | Value |
|---|---|
| Power supply type | USB |
| Power consumption (max) | 15 W |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 247 mm |
| Depth | 49.6 mm |
| Height | 13 mm |
| Weight | 122 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 201 mm |
| Package depth | 90 mm |
| Package height | 25 mm |
| Package weight | 122 g |
Other features
| Specification | Value |
|---|---|
| Maximum operating temperature | 40 °C |
