4XH1C12753 laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Black
Model 4XH1C12753EAN 195477705890
28 specifications
- ConnectivityWired
- Weight50 g
- ColourBlack
- Ethernet LANNo
- Power source typeUSB
- Operating temperature (T-T)5 - 35 °C
Overview
- Connectivity
- Wired
- Weight
- 50 g
- Colour
- Black
- Ethernet LAN
- No
- Power source type
- USB
- Operating temperature (T-T)
- 5 - 35 °C
- Brand
- Lenovo
- Category
- Laptop Docks & Port Replicators
- Model
- 4XH1C12753
- Part number
- 4XH1C12753
- EAN / UPC
- 195477705890
- Also known as
- Lenovo 4XH1C12753 laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Black
Specifications
28 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Microphone in | No |
| Headphone outputs | 0 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Maximum refresh rate | 60 Hz |
| Certification | CE,UL,CB FCC VCCI RCM KCC BSMI EAC |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
| Power connector | USB Type-C |
| Power consumption (max) | 20 W |
| Power cable length | 0.0606 m |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 8 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100.1 mm |
| Depth | 40 mm |
| Height | 12.1 mm |
| Weight | 50 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 132 mm |
| Package weight | 100 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
