40BG0135GE laptop dock/port replicator Docking Thunderbolt 4 Black
Model 40BG0135GE
46 specifications
- ConnectivityDocking
- Weight547.5 g
- ColourBlack
- Ethernet LANYes
- Power source typeAC
- Operating temperature (T-T)0 - 40 °C
Overview
- Connectivity
- Docking
- Weight
- 547.5 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Lenovo
- Category
- Laptop Docks & Port Replicators
- Model
- 40BG0135GE
- Part number
- 40BG0135GE
- Also known as
- Lenovo 40BG0135GE laptop dock/port replicator Docking Thunderbolt 4 Black
Specifications
46 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Docking |
| Host interface | Thunderbolt 4 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.1 |
| USB Power Delivery up to | 100 W |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Thunderbolt 4 ports quantity | 1 |
| Microphone in | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 2500 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Colour name | Eclipse Black |
| Card reader integrated | No |
| Data transfer rate | 40 Gbit/s |
| HD type | 8K Ultra HD |
| Maximum refresh rate | 60 Hz |
| Number of displays supported | 4 |
| Cable lock slot | Yes |
| Cable lock slot type | MicroSaver, Nano |
| On/off switch | Yes |
| Certification | FCC/ICES,CE,KCC,RCM,BSMI,NCC,VCCI,CB,cULus,EAC,TUV-Mark,LoA,Ukraine DoC,NOM,IFT,TELEC,UKCA,FAC DoC,VNTA,WPC ETA,SRRC,SDPPI,IMDA,SIRIM,NBTC, SUBTEL,KVALITET/RATEL,MCIT,ANRT,UCC,INACOM,CITRA,TRA,NTC,PSRC,NCA,ARTCI,INCM,Thunderbolt Cert.,EVO |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power supply | 135 W |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 220 mm |
| Depth | 80 mm |
| Height | 30 mm |
| Weight | 547.5 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 237.8 mm |
| Package depth | 141 mm |
| Package height | 75.8 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC |
