Lenovo 40AF0135IT laptop dock/port replicator Wired USB 3.2 Gen 2 (3.1 Gen 2) Type-C Black
Model 40AF0135ITEAN 191999788342
34 specifications
- ConnectivityWired
- Weight475 g
- ColourBlack
- Ethernet LANYes
- Power source typeDC
- Width210 mm
Overview
- Connectivity
- Wired
- Weight
- 475 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- DC
- Width
- 210 mm
- Brand
- Lenovo
- Category
- Laptop Docks & Port Replicators
- Model
- 40AF0135IT
- Part number
- 40AF0135IT
- EAN / UPC
- 191999788342, 5715063023495
- Also known as
- Lenovo 40AF0135IT laptop dock/port replicator Wired USB 3.2 Gen 2 (3.1 Gen 2) Type-C Black
Specifications
34 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 2 |
| DisplayPorts quantity | 2 |
| Microphone in | Yes |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Brand compatibility | Lenovo |
| Compatibility | E580, E480, E470, L580, L480, L470, L380, L380 Yoga, Lenovo Tablet 10, Miix 520-12IKB, T580, T570, T480, T480s, T470, T470s, T460, ThinkPad 25, X1 Carbon Gen 6, X1 Carbon Gen 5, X1 Yoga Gen 3, X1 Yoga Gen 2, X1 Tablet Gen 3, X1 Tablet Gen 2, 13 Gen 3 Windows, X280, X270, X260 |
| Certification | BSMI, CB, CE, cULus, EAC, FCC/ICES, Israel SII, KCC, LoA, NOM, RCM, Serbia Kvalitet, TUV Mark, Ukraine DoC, VCCI |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power supply | 135 W |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 80 mm |
| Height | 30 mm |
| Weight | 475 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 270 mm |
| Package depth | 165 mm |
| Package height | 88 mm |
| Package weight | 1.35 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | USB |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
