SD4839P USB-C Triple Video Dock - UK
Model SD4839PPart no. K33480UKEAN 5028252633536
67 specifications
- ConnectivityWired
- Weight270 g
- ColourBlack
- Ethernet LANYes
- Power source typeDC
- Windows operating systems supportedWindows 10, Windows 11
Overview
- Connectivity
- Wired
- Weight
- 270 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- DC
- Windows operating systems supported
- Windows 10, Windows 11
- Brand
- Kensington
- Category
- Laptop Docks & Port Replicators
- Model
- SD4839P
- Part numbers
- K33480UK, K33480EU, K33480AP
- EAN / UPC
- 5028252633536, 5028252633505, 5028252633499
- Also known as
- Kensington SD4839P USB-C Triple Video Dock - UK
Specifications
67 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 85 W |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
| HDCP | Yes |
| HDCP version | 1.4/2.2 |
| USB Type-C DisplayPort Alternate Mode | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Data transfer rate | 10 Gbit/s |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Maximum refresh rate | 60 Hz |
| Number of displays supported | 3 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| LED indicators | Power |
| Plug and Play | Yes |
| Country of origin | China |
| Certification | CE, CB, ErP, FCC, ICES, UKCA, VCCI, ACCO RSL |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| AC input voltage | 100 - 240 V |
| Input current | 2.5 A |
| Output current | 6.75 A |
| Output voltage | 20 V |
| Power consumption (max) | 135 W |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 11 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | 0 - 60 °C |
| Operating relative humidity (H-H) | 0 - 55% |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 180 mm |
| Height | 22 mm |
| Weight | 270 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 101 mm |
| Package depth | 196 mm |
| Package height | 101 mm |
| Package weight | 1.05 kg |
Packaging content
| Specification | Value |
|---|---|
| Warranty card | Yes |
| AC adapter included | Yes |
| Cables included | USB Type-C |
| User guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Master (outer) case gross weight | 8 kg |
| Master (outer) case height | 155 mm |
| Master (outer) case length | 455 mm |
| Master (outer) case width | 250 mm |
| Products per master (outer) case | 4 pc(s) |
