UH1510P EQ USB-C 5Gbps Triple Video Driverless Mobile Dock –
85W Pass-Through Power – DP/HDMI
Model K34040WWEAN 085896340409
49 specifications
- ConnectivityWired
- Weight154 g
- ColourBlack
- Ethernet LANYes
- Power source typeUSB
- Other operating systems supportediPadOS
Overview
- Connectivity
- Wired
- Weight
- 154 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- USB
- Other operating systems supported
- iPadOS
- Brand
- Kensington
- Category
- Laptop Docks & Port Replicators
- Model
- K34040WW
- Part number
- K34040WW
- EAN / UPC
- 085896340409
- Also known as
- Kensington UH1510P EQ USB-C 5Gbps Triple Video Driverless Mobile Dock – 85W Pass-Through Power – DP/HDMI
Specifications
49 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 0 |
| USB 2.0 Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 85 W |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Microphone in | No |
| Headphone outputs | 0 |
| HDCP | Yes |
| HDCP version | 2.3 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Number of displays supported | 3 |
| Housing material | Polycarbonate (PC) |
| Plug and Play | Yes |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
| USB cable length | 0.17 m |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterp |
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia |
| Other operating systems supported | iPadOS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 0 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 71 mm |
| Height | 21 mm |
| Weight | 154 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 180 mm |
| Package depth | 130 mm |
| Package height | 35 mm |
| Package weight | 180 g |
Packaging content
| Specification | Value |
|---|---|
| Warranty card | Yes |
| Quick start guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CB, CE, RCM, RoHS, UKCA, VCCI |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 10 pc(s) |
