j5create JCD393 4K60 Elite USB-C® 10Gbps Mini Dock, Space Grey
j5create

JCD393 4K60 Elite USB-C® 10Gbps Mini Dock, Space Grey

Model JCD393Part no. JCD393-NEAN 4712795086263

68 specifications
  • ConnectivityWired
  • Weight104 g
  • ColourGrey
  • Ethernet LANYes
  • Power source typeUSB
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Connectivity
Wired
Weight
104 g
Colour
Grey
Ethernet LAN
Yes
Power source type
USB
Operating temperature (T-T)
0 - 40 °C
Brand
j5create
Model
JCD393
Part number
JCD393-N
EAN / UPC
4712795086263
Also known as
j5create JCD393 4K60 Elite USB-C® 10Gbps Mini Dock, Space Grey

Specifications

68 specifications in 12 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity2
USB Power Delivery (USB PD)Yes
USB Power Delivery revision3.0
USB Power Delivery up to100 W
HDMI ports quantity1
HDMI version2.0
Microphone inNo
Headphone outputs0
USB Type-C DisplayPort Alternate ModeYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s

Performance

Product colourGrey
Colour nameSpace Grey
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), SD
Data transfer rate10 Gbit/s
HD type4K Ultra HD
Maximum digital resolution3840 x 2160 pixels
Maximum refresh rate144 Hz
Number of displays supported1
Display modesExtended, Mirror, Primary display
Charging functionYes
Housing materialAluminium
Plug and PlayYes
Country of originTaiwan
CompatibilityAvailable USB-C® port that supports DisplayPort™ alternate mode and USB™ Power Delivery 2.0 or 3.0

Power

Power source typeUSB
Power connectorUSB Type-C
Output current0.69 A
Output voltage5 V
Power consumption (typical)3.48 W
USB cable length0.2 m

Software

Windows operating systems supportedYes
Mac operating systems supportedYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-17 - 68 °C
Operating relative humidity (H-H)0 - 85%
Storage relative humidity (H-H)0 - 85%

Weight & dimensions

Width138 mm
Depth50 mm
Height16 mm
Weight104 g

Packaging data

Quantity per pack1 pc(s)
Package width193 mm
Package depth125 mm
Package height22.5 mm
Package weight164 g

Packaging content

ManualYes
Quick start guideYes

Technical details

Master (outer) case GTIN (EAN/UPC)24712795086267
Warranty period2 year(s)

Logistics data

Export Control Classification Number (ECCN)EAR99
Master (outer) case gross weight4.06 kg
Master (outer) case height190 mm
Master (outer) case length445 mm
Master (outer) case width226 mm
Products per master (outer) case18 pc(s)
Products per shipping (inner) case6 pc(s)
Shipping (inner) case width16.5 cm
Shipping (inner) case length21.2 cm
Shipping (inner) case height13.7 cm
Shipping (inner) case net weight1.14 kg

Other features

Special featuresBuilt-in advanced USB-C® E-Mark integrates USB4™, Thunderbolt™ 3 and Thunderbolt™ 4 compatibility, Features a 4K HDMI™ output, supporting video resolutions up to 3840 x 2160 at 60 Hz
