j5create JCD391 4K60 Elite USB-C® PD Multi-Port Adapter, Silver
j5create

JCD391 4K60 Elite USB-C® PD Multi-Port Adapter, Silver

Model JCD391Part no. JCD391-NEAN 4712795086379

63 specifications
  • ConnectivityWired
  • Weight74.8 g
  • ColourSilver
  • Ethernet LANYes
  • Output current0.4 A
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Connectivity
Wired
Weight
74.8 g
Colour
Silver
Ethernet LAN
Yes
Output current
0.4 A
Operating temperature (T-T)
0 - 40 °C
Brand
j5create
Model
JCD391
Part number
JCD391-N
EAN / UPC
4712795086379
Also known as
j5create JCD391 4K60 Elite USB-C® PD Multi-Port Adapter, Silver

Specifications

63 specifications in 12 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB Power Delivery (USB PD)Yes
USB Power Delivery revision3.0
USB Power Delivery up to85 W
HDMI ports quantity1
Microphone inNo
Headphone outputs0
USB Type-C DisplayPort Alternate ModeYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s

Performance

Product colourSilver
Card reader integratedNo
Data transfer rate5 Gbit/s
Maximum refresh rate60 Hz
Number of displays supported1
Display modesExtended, Mirror, Primary display
Housing materialAluminium
Plug and PlayYes
Country of originTaiwan
CompatibilityAvailable USB-C® port that supports DisplayPort™ alternate mode and USB™ Power Delivery 2.0 or 3.0.
CertificationWorks with Chromebook

Power

Output current0.4 A
Output voltage20 V
Power consumption (typical)2 W
USB cable length0.2 m

Software

Windows operating systems supportedYes
Mac operating systems supportedYes
Other operating systems supportedChromeOS

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-17 - 68 °C
Operating relative humidity (H-H)0 - 85%
Storage relative humidity (H-H)0 - 85%

Weight & dimensions

Width66.5 mm
Depth14.7 mm
Height77.6 mm
Weight74.8 g

Packaging data

Quantity per pack1 pc(s)
Package width155 mm
Package depth95 mm
Package height30.8 mm
Package weight129 g

Packaging content

Cables includedUSB Type-C
ManualYes
Quick start guideYes

Technical details

Master (outer) case GTIN (EAN/UPC)24712795086373
Warranty period2 year(s)

Logistics data

Export Control Classification Number (ECCN)EAR99
Master (outer) case gross weight3.88 kg
Master (outer) case height190 mm
Master (outer) case length435 mm
Master (outer) case width230 mm
Products per master (outer) case24 pc(s)
Products per shipping (inner) case6 pc(s)
Shipping (inner) case width10.3 cm
Shipping (inner) case length21.8 cm
Shipping (inner) case height16.5 cm
Shipping (inner) case net weight870 g

Other features

Special featuresChromebook™ Certified, 5-in-1 Functions, 86W of Pass-Through Charging
