JCD390 4K60 Elite USB-C® 10Gbps Multi-Adapter, Black
Model JCD390-NEAN 4712795087390
61 specifications
- ConnectivityWired
- Weight70 g
- ColourSilver, White
- Ethernet LANNo
- Power source typeUSB
- Windows operating systems supportedYes
Overview
- Connectivity
- Wired
- Weight
- 70 g
- Colour
- Silver, White
- Ethernet LAN
- No
- Power source type
- USB
- Windows operating systems supported
- Yes
- Brand
- j5create
- Category
- Laptop Docks & Port Replicators
- Model
- JCD390-N
- Part number
- JCD390-N
- EAN / UPC
- 4712795087390
- Also known as
- j5create JCD390 4K60 Elite USB-C® 10Gbps Multi-Adapter, Black
Specifications
61 specifications in 13 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| HDMI ports quantity | 1 |
| Microphone in | No |
| Headphone outputs | 0 |
| USB Type-C DisplayPort Alternate Mode | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
Performance
| Specification | Value |
|---|---|
| Product colour | Silver, White |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Data transfer rate | 10 Gbit/s |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Maximum refresh rate | 144 Hz |
| Housing material | Acrylonitrile butadiene styrene (ABS), Aluminium, Plastic |
| Country of origin | Taiwan |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
| Input current | 5 A |
| Output current | 4.75 A |
| Output voltage | 20 V |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Other operating systems supported | ChromeOS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -1 - 41 °C |
| Storage temperature (T-T) | -17 - 68 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 85% |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 126.5 mm |
| Depth | 200 mm |
| Height | 32.6 mm |
| Weight | 70 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 190 mm |
| Package depth | 85 mm |
| Package height | 17.5 mm |
| Package weight | 120 g |
Packaging content
| Specification | Value |
|---|---|
| Packaging content | 1 - JCD390 4K60 Elite USB-C® 10Gbps Multi-Adapter 1 - Quick Installation Guide (QIG) |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, REACH, RoHS |
| Master (outer) case GTIN (EAN/UPC) | 24712795087394 |
| Warranty period | 2 year(s) |
Logistics data
| Specification | Value |
|---|---|
| Export Control Classification Number (ECCN) | EAR99 |
| Master (outer) case height | 115 mm |
| Master (outer) case length | 266 mm |
| Master (outer) case net weight | 1.9 kg |
| Master (outer) case width | 225 mm |
| Products per master (outer) case | 12 pc(s) |
| Products per shipping (inner) case | 6 pc(s) |
| Shipping (inner) case width | 12.5 cm |
| Shipping (inner) case length | 21.5 cm |
| Shipping (inner) case height | 9.2 cm |
| Shipping (inner) case net weight | 800 g |
Other features
| Specification | Value |
|---|---|
| Cable length | 0.2 m |
