12-in-1 DockingStation with triple video output
Model IB-DK4062-CPDPart no. 61190EAN 4250078175247
46 specifications
- ConnectivityWired
- Weight135 g
- ColourAnthracite
- Ethernet LANYes
- Power source typeUSB
- Width55 mm
Overview
- Connectivity
- Wired
- Weight
- 135 g
- Colour
- Anthracite
- Ethernet LAN
- Yes
- Power source type
- USB
- Width
- 55 mm
- Brand
- ICY BOX
- Category
- Laptop Docks & Port Replicators
- Model
- IB-DK4062-CPD
- Part number
- 61190
- EAN / UPC
- 4250078175247
- Also known as
- ICY BOX 12-in-1 DockingStation with triple video output
Specifications
46 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 2 |
| USB 2.0 Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| HDMI ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Microphone in | Yes |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| USB Type-C DisplayPort Alternate Mode | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Anthracite |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Data transfer rate | 5 Gbit/s |
| HD type | 4K Ultra HD |
| Maximum refresh rate | 60 Hz |
| Housing material | Aluminium |
| Plug and Play | Yes |
| UASP support | Yes |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
| Power connector | USB Type-C |
| Power cable length | 0.2 m |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mobile operating systems supported | Android |
| Other operating systems supported | ChromeOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 55 mm |
| Depth | 133 mm |
| Height | 17 mm |
| Weight | 135 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 100 mm |
| Package depth | 200 mm |
| Package height | 25 mm |
| Package weight | 200 g |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
