IB-DK2701-TB3 Wired Thunderbolt 3 Black
Model IB-DK2701-TB3Part no. 60405EAN 4250078168669
51 specifications
- ConnectivityWired
- Weight593 g
- ColourBlack
- Ethernet LANYes
- Power source typeDC
- Width238 mm
Overview
- Connectivity
- Wired
- Weight
- 593 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- DC
- Width
- 238 mm
- Brand
- ICY BOX
- Category
- Laptop Docks & Port Replicators
- Model
- IB-DK2701-TB3
- Part number
- 60405
- EAN / UPC
- 4250078168669
- Also known as
- ICY BOX IB-DK2701-TB3 Wired Thunderbolt 3 Black
Specifications
51 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | Thunderbolt 3 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 2.0 |
| USB Power Delivery up to | 70 W |
| HDMI ports quantity | 0 |
| DisplayPorts quantity | 1 |
| Thunderbolt 3 ports quantity | 2 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Data transfer rate | 10 Gbit/s |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Charging function | Yes |
| Housing material | Aluminium, Plastic |
| LED indicators | Yes |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| AC input voltage | 100 - 240 V |
| Power supply | 135 W |
| Output current | 6.75 A |
| Output voltage | 20 V |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 238 mm |
| Depth | 85 mm |
| Height | 31 mm |
| Weight | 593 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 290 mm |
| Package depth | 92 mm |
| Package height | 160 mm |
| Package weight | 1.48 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC, Thunderbolt |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Master (outer) case gross weight | 10 kg |
| Master (outer) case height | 225 mm |
| Master (outer) case length | 500 mm |
| Master (outer) case width | 305 mm |
| Products per master (outer) case | 6 pc(s) |
